SC200EWFDA-G55-UNNNA SMD alum electrolytic 200V rated 105°C low impedance long life high ripple -40 to +105°C for power and LED

SC200EWFDA-G55-UNNNA SMD alum electrolytic 200V rated 105°C low impedance long life high ripple -40 to +105°C for power and LED

Features

• SMD Aluminum Electrolytic Construction – Ideal for automated pick-and-place PCB assembly.

• 200V DC Rated Voltage – Suitable for high-voltage bus filtering in power conversion circuits.

• 105°C Maximum Operating Temperature – Withstands elevated ambient temperatures in industrial and automotive environments.

• Low Impedance (at 100kHz) – Improves high-frequency filtering performance for switching power supplies.

• High Ripple Current Capability – Handles AC ripple in rectification and smoothing stages without overheating.

• Long Load Life – Typically rated for 2,000 to 5,000 hours at 105°C (confirm with datasheet).

• -40°C to +105°C Wide Temperature Range – Reliable operation in cold start and high-heat conditions.

Applications

• Switched-Mode Power Supplies (SMPS) – Output filtering and bulk storage after rectification.

• LED Lighting Drivers – Smoothing high-voltage DC rails for constant current LED strings.

• Industrial Power Modules – Input/output filtering for motor drives, inverters, and industrial controllers.

• Automotive Electronics – On-board charging, DC-DC converters, and infotainment power filters (12V–48V systems stepped up to 200V).

• Home Appliances – Power boards in air conditioners, washing machines, and induction cooktops.

• Telecom & Networking Equipment – Base station power supplies and POE injectors requiring 200V bulk capacitance.

• Renewable Energy – DC-link capacitors in solar microinverters and small wind turbine controllers.

Description

The SC200EWFDA-G55-UNNNA is an SMD (surface mount) aluminum electrolytic capacitor designed for high-voltage and high-temperature applications. Featuring a rated voltage of 200V and an operating temperature range of -40°C to +105°C, this component offers stable capacitance and low impedance over extended periods. Its non-solid electrolyte design combined with a high ripple current capability makes it suitable for power supply filtering, LED lighting drivers, and industrial electronics where board space is limited. The G55 case size and UNNNA packaging code indicate tape-and-reel delivery for automated assembly.
