FP75R12KT4 B16 1200V 150A PIM IGBT Module Trench Field Stop Low VCE(sat) 2.25V Integrated Rectifier and NTC Copper Baseplate 150°C Operation For Motor Drives and UPS

FP75R12KT4 B16 1200V 150A PIM IGBT Module Trench Field Stop Low VCE(sat) 2.25V Integrated Rectifier and NTC Copper Baseplate 150°C Operation For Motor Drives and UPS

Features

• 1200V / 150A PIM (Power Integrated Module)

• Integrated Topology: 3-Phase Rectifier, 3-Phase Inverter, Brake Chopper

• Advanced TRENCHSTOP™ IGBT4 with Trench Field Stop Technology

• Low Switching Losses for High Efficiency

• Low VCE(sat) of 2.25V @ 15V, 75A

• Copper Baseplate for Optimized Heat Spread

• Integrated NTC Temperature Sensor

• Operating Temperature Range: -40°C ~ 150°C

• Compact EconoPIM™ 3 Housing with Chassis Mount

Applications

• Industrial Motor Drives: For pumps, fans, compressors, and general-purpose AC drives

• Uninterruptible Power Supplies (UPS)

• Variable Frequency Drives (VFD) and Inverters

• HVAC Systems and industrial automation

Description

The FP75R12KT4 B16 is a highly integrated 1200V, 150A Power Integrated Module (PIM) from Infineon's EconoPIM™ 3 family . It combines a three-phase rectifier bridge, a three-phase IGBT inverter bridge, and a brake chopper in a single, compact, and isolated module . Built with advanced TRENCHSTOP™ IGBT4 technology featuring a Trench Field Stop structure, it is engineered for low switching losses and high efficiency . The module achieves a low collector-emitter saturation voltage of 2.25V typical at 75A, enhancing energy efficiency . It features an integrated NTC temperature sensor for accurate thermal monitoring and a copper baseplate for optimized heat dissipation . Designed for high reliability, it supports an extended operating temperature up to 150°C
