FP50R12KT4 1200V 50A PIM IGBT Module TRENCHSTOP™ IGBT4 Low Switching Loss Integrated Rectifier and Brake Copper Baseplate NTC High Switching Frequency For Motor Drives and HVAC

FP50R12KT4 1200V 50A PIM IGBT Module TRENCHSTOP™ IGBT4 Low Switching Loss Integrated Rectifier and Brake Copper Baseplate NTC High Switching Frequency For Motor Drives and HVAC

Features

• 1200V / 50A PIM (Power Integrated Module)

• Integrated Topology: 3-Phase Rectifier, 3-Phase Inverter, Brake Chopper

• Advanced TRENCHSTOP™ IGBT4 and Emitter Controlled 4 Diode

• Low Switching Losses for High Efficiency

• Low VCE(sat) of 1.85V (typical)

• Copper Base Plate for Optimized Heat Spread

• Integrated NTC Temperature Sensor

• Low Stray Inductance Module Design

• High Switching Frequency Capability

• Compact EconoPIM™ 2 Housing

Applications

• Motor Control and Industrial Drives: For pumps, fans, compressors, and general-purpose AC drives .

• Uninterruptible Power Supplies (UPS) .

• Commercial HVAC Systems and HVAC Control Modules .

• Industrial Heating and Welding Equipment .

• Renewable Energy Systems including wind power applications .

• Room Air Conditioners

Description

The FP50R12KT4 is a highly integrated 1200V, 50A Power Integrated Module (PIM) from Infineon's EconoPIM™ 2 family . It combines a three-phase rectifier bridge, a three-phase IGBT inverter bridge, and a brake chopper in a single, compact, and isolated module . Built with advanced TRENCHSTOP™ IGBT4 and Emitter Controlled 4 diode technology, it is engineered for low switching losses and high efficiency . The module features an integrated NTC temperature sensor for accurate thermal monitoring, a copper base plate for optimized heat spread, and low stray inductance design for reliable performance . It supports high switching frequency operation and is available with solderable pins or PressFIT technology
