DZ1070N22K 2200V 1070A HiPak IGBT Module Low VCE(sat) High Short Circuit Ruggedness Low Switching Loss Press-Fit Technology For HVDC and High Power Traction Drives

DZ1070N22K 2200V 1070A HiPak IGBT Module Low VCE(sat) High Short Circuit Ruggedness Low Switching Loss Press-Fit Technology For HVDC and High Power Traction Drives

Features

• Ultra-High-Power HiPak IGBT Module

• Voltage/Current Rating: 2200V / 1070A

• Advanced IGBT and Diode Chip Technology

• Low VCE(sat) and Low Switching Losses

• Very High Short-Circuit Ruggedness (SCWT)

• Low-Inductance Design

• Press-Fit Contact Technology

• Integrated Temperature Monitoring

• Designed for High Reliability and Long Service Life

Applications

• High-Voltage Direct Current (HVDC) Transmission Stations: For voltage source converter (VSC) valves.

• Rail Traction: Main propulsion converters for high-power locomotives and high-speed trains.

• Large Industrial Motor Drives: For the largest motors in mining, marine, and metal processing.

• Power Quality and Grid Stability Systems: Such as STATCOMs and large-scale active filters.

• Specialized High-Power Test and Research Equipment.

Description

The DZ1070N22K is an ultra-high-voltage, ultra-high-current HiPak IGBT module engineered for the most demanding and critical applications in power transmission and heavy traction. It delivers an ultra-high blocking voltage of 2200V and an exceptional current rating of 1070A, positioning it at the forefront of high-power conversion technology. Built with advanced trench gate/field-stop IGBT and optimized diode chip technology, it achieves an excellent balance of low conduction losses (VCE(sat)) and low switching losses for high system efficiency. The module is designed for ultimate ruggedness and long-term reliability, featuring very high short-circuit withstand capability, low internal inductance, and robust Press-Fit contact technology for solder-free, reliable power connections in systems that require maximum uptime and minimal maintenance.
