Features

• Intelligent Power Module (IPM)

• 600V / 80A Rating

• Integrated 3-Phase IGBT Inverter Bridge and HVIC Drivers

• Built-in Bootstrap Diodes

• Comprehensive Protection (UVLO, Short-Circuit, Over-Temperature)

• Low Saturation Voltage IGBTs and Fast Recovery Diodes

• Compact, Isolated DIP Package

• Low-Electromagnetic-Interference (Low-EMI) Design

• High Reliability and Ease of Use

Applications

• Industrial AC Motor Drives: For pumps, fans, compressors, and conveyor systems.

• Variable Frequency Drives (VFD) and Inverters.

• Uninterruptible Power Supplies (UPS): Inverter stages.

• Appliances and HVAC Systems: Air conditioner compressors and fan drives.

Description

The 6MBP80RTA060F-01 is a highly integrated Intelligent Power Module (IPM) designed to simplify and enhance the reliability of medium-power motor drive and inverter systems. It combines a complete three-phase IGBT inverter bridge, high-voltage gate drivers (HVIC), bootstrap diodes, and comprehensive protection circuits within a single, compact DIP package. Rated for 600V and 80A operation, it utilizes low-loss IGBTs and fast-recovery freewheeling diodes for high efficiency. The built-in protection features include under-voltage lockout (UVLO), over-current/short-circuit protection (SC), and thermal shutdown, which safeguard the system under fault conditions. This all-in-one solution minimizes external component count, simplifies PCB layout, and accelerates development time while ensuring robust and reliable operation.
