SKD83 16 1600V 83A Dual Diode Module Ultra-Low Forward Voltage Fast Soft Recovery High Surge Current High Isolation Robust EconoDUAL3 Package For Heavy-Duty Rectifiers and Industrial Welding
Features
-
Dual Diode Configuration
-
Ultra-High Current Rating: 83A (IAV)
-
High Voltage Rating: 1600V (VRRM)
-
Ultra-Low Forward Voltage Drop (VF)
-
Fast Soft Recovery Characteristics
-
Exceptional Surge Current Capability (IFSM)
-
High Isolation Voltage
-
Rugged, Isolated EconoDUAL3-Type Package
-
Heavy-Duty Industrial Grade Construction
Applications
-
Heavy-Duty Industrial Rectifiers: Three-phase bridge rectifiers in high-power motor drives, mining equipment, and large UPS systems.
-
Industrial and Professional Welding Power Supplies:
-
High-Power Battery Charging Systems for electric vehicles or energy storage.
-
Power Supplies for Plasma Cutting and Electrolysis.
-
AC/DC Front-Ends for Multi-Megawatt Inverters and Converters.
Description
The SKD83 16 is an ultra-high-current, high-voltage dual diode module designed for the most demanding heavy-duty industrial rectification and power conversion systems. It integrates two high-performance diodes in a robust, isolated package, each rated for a repetitive peak reverse voltage of 1600V and an impressive average forward current of 83A. The diodes are engineered with an ultra-low forward voltage drop to maximize efficiency and minimize thermal losses, coupled with fast soft recovery characteristics to reduce switching losses and electromagnetic interference (EMI). Its exceptional surge current capability, high isolation, and rugged EconoDUAL3-style package ensure ultimate reliability and performance in the toughest applications.
INFORMATION
| Current (A) |
83 A
|
| Dimensions (LxWxH) |
63.5x29.5x17
|
| Features |
- Glass passivated silicon chips
- Low thermal impedance through use of direct copper bonded aluminum substrate (DCB) base plate
- Blocking voltage up to 1800 V
- Suitable for PCB mounting and wave soldering
- For applications with high vibrations we recommend to fasten the bridge to the pcb with 4 selftapping screw
|
| Housing |
G55
|
| Legacy part number |
07232910
|
| Product line |
Power Bridge
|
| Product Status |
In Production
|
| Surge current (A) |
560 A
|
| Technology |
Bridge
|
| Topology |
Rectifier
|
| Type |
G55
|
| Typical applications |
- Three phase rectifiers for power supplies
- Input rectifiers for variable frequency drives
- Rectifiers for DC motor field supplies
- Battery charger rectifiers
|
| Voltage (V) |
1600 V
|
Drawing
