BSM150GD120DN2 1200V/150A IGBT Module Low VCE(sat) High Speed Switching Low Loss Built-in NTC Isolated Baseplate Industrial Grade for Heavy-Duty Motor Drives & Wind Power Inverters

BSM150GD120DN2 1200V/150A IGBT Module Low VCE(sat) High Speed Switching Low Loss Built-in NTC Isolated Baseplate Industrial Grade for Heavy-Duty Motor Drives & Wind Power Inverters

Features

• Voltage/Current Rating: 1200 V / 50 A

• Configuration: Dual IGBT

• Low Saturation Voltage: VCE(sat) for reduced conduction losses.

• Low Switching Losses: Optimized for high-frequency operation.

• Built-in NTC Thermistor: Enables thermal monitoring and protection.

• Isolated Baseplate: Facilitates easy and safe heatsink assembly.

• High Reliability: Industrial-grade robustness for long service life.

• Low Thermal Impedance: Efficient heat dissipation capability.

Applications

• Industrial Motor Drives: For controlling AC motors in pumps, fans, compressors, and conveyor systems.

• Solar Inverters: Used in the power conversion stage of photovoltaic inverter systems.

• Uninterruptible Power Supplies (UPS): Employed in the inverter section of high-capacity UPS systems.

• Welding Equipment: Serves as the key switching component in industrial welding machines.

• Induction Heating: Provides reliable power switching for induction heating systems.

Description

The BSM150GD120DN2 is a high-power dual IGBT module engineered for the most demanding industrial power conversion applications. With a robust rating of 1200V and 150A, it delivers exceptional performance and reliability in high-current circuits. The module is optimized for efficiency, featuring a very low collector-emitter saturation voltage (VCE(sat)) and low switching losses, which are critical for minimizing power dissipation in high-power systems.

This module incorporates essential protection and thermal management features, including a built-in NTC thermistor for precise temperature monitoring and a fully isolated baseplate for safe and efficient heatsink mounting. Its industrial-grade construction ensures superior thermal cycling capability and long-term operational stability under strenuous conditions.
