NCP3063BDR2G Electronic components integrated circuits semiconductor New Original IC
This Buck Boost Inverting Switching Regulator consists of an internal temperature compensated reference, comparator, controlled duty cycle oscillator with an active current limit circuit, driver and high current output switch. New features include an internal thermal shutdown protection and cycle-by-cycle current limit. This series was specifically designed to be incorporated in step-down (buck) and step-up (boost) and voltage-inverting applications with a minimum number of external components. The NCV3063 is available for automotive applications.
| Function |
Step-Up, Step-Down |
| Output Configuration |
Positive or Negative |
| Topology |
Buck, Boost |
| Output Type |
Adjustable |
| Number of Outputs |
1 |
| Voltage - Input (Min) |
3V |
| Voltage - Input (Max) |
40V |
| Voltage - Output (Min/Fixed) |
1.25V |
| Voltage - Output (Max) |
40V (Switch) |
| Current - Output |
1.5A (Switch) |
| Frequency - Switching |
150kHz |
| Synchronous Rectifier |
No |
| Operating Temperature |
-40°C ~ 125°C (TJ) |
| Mounting Type |
Surface Mount |
| Package / Case |
8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package |
8-SOIC |
Our advantage :
- High quality products --- our offers are 100% new and original, ROHS
- Competitive price --- good Purchase channels with good price.
- Professional service --- strict quality testing before the shipment, and perfect after-sales service after the purchase.
- Adequate inventory --- With the support of our strong Purchasing team,
- Fast delivery --- we will ship the goods within 1-3 working days after the payment confirmed.
be sure to meet your need for all kinds of components. ^_^
