High Gain Combination Active Antenna GPS WIFI with RG174 Cable

Good quality 3G Modem Module for sales
Good quality 3G Modem Module for sales
Excellent product , good quality , competitive price , professional service , with 10 years cooperation , now we become good friends each other.

—— Ronald-from Boilvia

It is very glad to find TOP as our partner in China , here we can get the best Product and serice , they always put the customer at the first place.

—— Carlos-from Argentina

I am very satisfied with all your service. It is really a good team! with your one-stop solution offer , help us to save much time and money

—— Giancarlo-from Italy

I'm Online Chat Now

High Gain Combination Active Antenna GPS WIFI with RG174 Cable

China High Gain Combination Active Antenna GPS WIFI with RG174 Cable supplier
High Gain Combination Active Antenna GPS WIFI with RG174 Cable supplier High Gain Combination Active Antenna GPS WIFI with RG174 Cable supplier High Gain Combination Active Antenna GPS WIFI with RG174 Cable supplier

Large Image :  High Gain Combination Active Antenna GPS WIFI with RG174 Cable

Product Details:

Place of Origin: China
Brand Name: TOP
Certification: CE,ROHS
Model Number: TOP-GPS/WIFI03

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Price: 6.2$ ~6.8$/pcs
Packaging Details: 1pcs/box, 100 box/carton
Delivery Time: 5-7 working days after getting the payment
Payment Terms: L/C, T/T,Paypal
Supply Ability: 100000pcs/month
Contact Now
Detailed Product Description
Product Name: GPS + WIFI Combo Antenna Size: D46.6*14.5 MM
Mounting Method: Magnetic Gain: 28 Dbi
Connector: SMA,SMB,BNC,FRAKA Etc Working Temp: -40℃~+85℃



High Gain Combination Active Antenna GPS WIFI with RG174 Cable



For this type also can be made as GPS+GLONASS combination ,

GPS+GSM+WIFI combination antenna.





Specification

Item

Specifications

GPS Antenna

Dielectric

Antenna

Center Frequency

1575.42±1MHz

Band Width

CF±3MHz

Polarization

RHCP

Gain

0dBic(Zenith)

V.S.W.R

<1.5

Impendance

50Ω

Axial Ratio

3dB

LNA

Gain

22±2dB

Noise Figure

<1.5

Ex-band Attenuation

35dB@CF±50MHz

V.S.W.R

<2.0

Supply Voltage

3V DC

Current Consumption

9mA

WIFI Antenna

Frequency Range

2400~2483.5/4800~5825MHz

V.S.W.R(min)

<2.5

Polarization

Linear

Gain

2dBi(Zenith)

Impendance

50Ω

Mechanical

Cable

RG174 or others

Connector

SMA  or others

Radome Material

ABS

Mounting Method

Screw

Environmental

Operating Temperature

-40℃~+85℃

Relative Humidity

Up to 95%

Ingress Protection

IP65~IP67 (exclude cable outlet)

Vibration

10 to 55Hz with 1.5mm amplitude 2hours

Environmentally Friendly

ROHS Compliant





Key feature:



(i)Dielectric Antenna
Center Frequency(MHz):1575.42±3
VSWR:1.5:1
Bandwidth(MHz):±5
Impedance(Ω):50
Peak Gain >3dBi Based on 7cm×7cm ground plane
Gain Coverage >-4dBi at –90°<0 <+90°(over 75% Volume)
Polarization:RHCP
(ii)GSM Antenna
Center Frequency(MHz):850/900/1800/1900
VSWR:2.0:1
Impedance(Ω):50
Typical Gain:2dBi+/-1dBi@850MHz ; 2dBi+/-1dBi@900MHz
                          1dBi+/-1dBi@1800MHz;1dBi+/-1dBi@1900MHz
(iii)LNA/Filter
LNA Gain(Without Cable) :28 dBi Typical
Noise Figure(dB):1.5
Filter Out Band Attenuation (f0=1575.42 MHz)
7dB Min f0+/-20MHz ;
20dB Min f0+/-50MHz;
30dB Min f0+/-100MHz
VSWR <2.0
DC Voltage(V):2.7/3.0/3.3/5.0/3.0 to 5.0 etc.
DC Current (mA):11 Max
(iv)Mechanical
Weight(gram )<150
Size(mm):Φ46×14.5
Cable GPS(m):RG174 2,5 long etc.
            GSM(m):RG174 2,5 long etc.
Connector GPS:SMA/SMB/SMC/BNC/FME/TNC/MCX/MMCX etc.
                    GSM:SMA/SMB/SMC/BNC/FME/TNC/MCX/MMCX etc.
Mounting:Screw(Hole/Roof)
Housing:Black
(v)Environmental
Working Temp:-40℃~+85℃
Storage Temp:-45℃~+100℃
Vibration:Sine sweep 1g(0-p)10~50~10Hz each axis
Humidity:Humidity95%~100%RH
Weatherproof:100%Waterproof





Application:

For M2M productions





Drawing of the Antenna:

High Gain Combination Active Antenna GPS WIFI with RG174 Cable















Please contact us for the data sheet
