TPS62822DLCR 2.25MHz 2A Step-Down Converter with 6.5μA IQ 1.8V-6.5V Input 0.6V±1% Ref 100% Duty Cycle Power Save Forced PWM and 2mmx2mm SON-8

TPS62822DLCR 2.25MHz 2A Step-Down Converter with 6.5andmu;A IQ 1.8V-6.5V Input 0.6Vandplusmn;1% Ref 100% Duty Cycle Power Save Forced PWM andamp; 2mmx2mm SON-8

andnbsp;

Features

andbull; DCS-Controlandtrade; topology

andbull; 26-mandOmega;/25-mandOmega; internal power switches (TPS62823)

andbull; Upto3-A output current (TPS62823)

andbull; Very low quiescent current of 4 andmicro;A

andbull; Switching frequency of typically 2.2 MHz

andbull; 1%feedback voltage accuracy (full temp. range)

andbull; Enable (EN) and power good (PG)

andbull; Adjustable output voltage from 0.6 V to 4 V

andbull; 100%duty-cycle mode

andbull; Internal soft-start circuitry

andbull; Seamless power save mode transition

andbull; Undervoltage lockout

andbull; Active output discharge

andbull; Cycle-by-cycle current limit

andbull; HICCUPshort-circuit protection

andbull; Over temperature protection

andbull; CISPR11 class B compliant

andnbsp;

Applications

andbull; POLsupply in portable/battery powered devices

andbull; Factory and building automation

andbull; Mobile computing, networking cards

andbull; Solid state drive

andbull; Data terminal, point of sale

andbull; Servers, projectors, printers

andnbsp;

Description

The TPS6282x is an all-purpose and easy to use synchronous step-down DC-DC converter with a very low quiescent current of only 4 andmicro;A. It supplies up to 3A output current (TPS62823) from a 2.4-V to 5.5-V input voltage. Based on the DCS-Controlandtrade; topology it provides a fast transient response.

The internal reference allows to regulate the output voltage down to 0.6 V with a high feedback voltage accuracy of 1% over the junction temperature range of-40anddeg;C to 125anddeg;C. The 1-A, 2-A, 3-A scalable pin-to pin and BOM-to-BOM compatible device family can be used with small 470-nH inductors.

The TPS6282x include an automatically entered power save mode to maintain high efficiency down to very light loads.

The device features a Power Good signal and an internal soft start circuit. It is able to operate in 100% mode. For fault protection, it incorporates a HICCUP current limit as well as a thermal shutdown.

The TPS6282x are packaged in a 2 mm x 1.5 mm QFN-8 package.

andnbsp;

INFORMATION

andnbsp;

Drawing

Our advantage :phones, PDAand#39;s, notebook comput.ers

• High quality products --- our offers are 100% new and original, ROHS
• Competitive price --- good Purchase channels with good price.
• Professional service --- strict quality testing before the shipment, and perfect after-sales service after the purchase.
• Adequate inventory --- With the support of our strong Purchasing team,
• Fast delivery --- we will ship the goods within 1-3 working days after the payment confirmed.

andnbsp;

be sure to meet your need for all kinds of components. ^_^


Product List
Supply a Series of Electronic Components, full range of semiconductors, active andamp; passive Components.We can help you to get all for bom of the PCB,IN a word, you can get one-stop solution here,


The offers including:
Integrated Circuit, Memory ICs, Diode, Transistor , Capacitor, Resistor, Varistor, Fuse, Trimmer andamp; Potentiometer, Transformer, Battery, Cable, Relay, Switch, Connector, Terminal Block, Crystal andamp; Oscillator, Inductor, Sensor, Transformer, IGBT Driver, LED,LCD, Convertor, PCB (Printed Circuit Board),PCBA (PCB Assembly)

Strong in Brand:
Microchip, MAX, AD, TI, ATMEL, ST, ON, NS, Intersil, Winbond, Vishay, ISSI, Infineon, NEC, FAIRCHILD, OMRON,YAGEO, TDK, etc
