LPC1788FBD208 DHX Original High Quality Electronic component

   LPC1788FBD208

ARM Cortex-M4F Core

• High-Performance Processing: Features a 32-bit ARM Cortex-M4F core with 120 MHz clock speed, supporting DSP instructions and FPU (Floating-Point Unit) for complex mathematical operations.
• Memory Protection Unit (MPU): Enhances system security by controlling memory access permissions.
• Low Power Consumption: Optimized for energy efficiency with multiple power-saving modes (Sleep, Deep-sleep, Power-down).

Rich Memory Configuration

• 512 KB Flash Memory: Stores program code with fast read access.
• 96 KB SRAM: Includes 32 KB of tightly coupled memory (TCM) for critical code execution.
• External Memory Interface: Supports SDRAM, SRAM, and Flash for expanded storage.

Comprehensive Peripherals

• Communication Interfaces:
  • USB 2.0: Full-speed device/host/OTG with on-chip PHY.
  • Ethernet: 10/100 MAC with DMA support for network applications.
  • CAN: Two CAN 2.0B interfaces for automotive and industrial communication.
  • UARTs/SPI/I2C: Multiple serial interfaces for versatile connectivity.
• Analog Features:
  • 12-bit ADC: Up to 12 channels with 4.5 MSPS sampling rate.
  • DAC: 10-bit digital-to-analog converter.
• Timers & PWM:
  • Multiple Timers: Including 32-bit general-purpose timers and PWM outputs for motor control.
  • SysTick Timer: Provides basic timing for the RTOS kernel.

Advanced Security

• Flash Read Protection: Prevents unauthorized code extraction.
• JTAG/SWD Debug Interfaces: Secure debug access with configurable protection levels.
• CRC Calculation Unit: Ensures data integrity for critical applications.

Package & Pinout

• 208-pin FBGA Package: Compact form factor (14 mm × 14 mm) with fine-pitch ball grid array.
• Extensive I/O Pins: Up to 160 GPIO pins with configurable pull-up/down resistors and interrupt capabilities.

Development Support

• Toolchain Compatibility: Supports Keil MDK, GCC, IAR Embedded Workbench, and other major IDEs.
• NXP SDK: Provides drivers, middleware, and example code for rapid development.
• Debugging & Trace: Comprehensive debug features via JTAG/SWD and Cortex-M4F core trace.

Applications

• Industrial Control: PLCs, motor drives, and automation systems.
• Automotive Electronics: Body control modules, infotainment systems, and sensor interfaces.
• Networking Devices: Ethernet switches, routers, and protocol converters.
• Consumer Electronics: Smart home devices, wearable technology, and IoT gateways

• 包装	托
  零件状态	积极
  DigiKey 可编程	未验证
  核心处理器	ARM® Cortex-M3® 系列
  核心尺寸	32 位单核
  速度	120兆赫(MHz)
  连接	CANbus,EBI/EMI,以太网,I2C,Microwire,存储卡,SPI,SSI,SSP,UART/USART,USB OTG
  外设	掉电检测/复位,DMA,I2S,LCD,电机控制 PWM,POR,PWM,WDT
  I/O 数量	165
  程序内存大小	512KB (512K x 8)
  程序内存类型	闪光
  EEPROM 尺寸	4K x 8
  RAM 大小	约96K x 8
  电压 - 电源 (Vcc/Vdd)	2.4V ~ 3.6V
  数据转换器	A/D 8x12b;D/A 1x10b
  振荡器类型	内部
  工作温度	-40°C ~ 85°C (技术含量)
  安装类型	表面贴装
  供应商设备包	208-LQFP (28x28)
  包装 / 外壳	208-LQFP 系列
  基本产品编号	LPC1788
