Brass Antenna Jump Pigtail RF Coaxial Cable with TNC Connector

large.img.alt
small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt

Large Image :  Brass Antenna Jump Pigtail RF Coaxial Cable with TNC Connector

Product Details:
Place of Origin: Shen Zhen,Guang Dong,China
Brand Name: TOP
Certification: CE,ROHS
Model Number: TOP-TNC-C01
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: 1.5$ ~2.5$/pcs
Packaging Details: 100pcs/PE bag
Delivery Time: 3-4 working days after receiving the payment
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 40k pcs/month
Detailed Product Description
Product Name: RF Coaxial Cable Connector: TNC Type Male - SMA
Insulator: PTFE Body: Brass
Operating Temperature: 45 °C-85 °C Bandwidth: 100 MHZ
High Light:

dual coaxial cable

,

hd coaxial cable

Brass Antenna Jump Pigtail RF Coaxial Cable with TNC Connector



Production  Introduction:

BNC Male  Cable Assemblies
RF cable is used for all RF/wireless equipments.
GSM SYSTEM
GPS NAVIGATION SYSTEM
WIRELESS COMMUNICATION SYSTEM
ANTENNAS
CAR RADIO
TEST EQUIPMENT
MICROWAVE COMPONENTS
DATA TRANSMISSION
LAN SYSTEM
SATELLITE TRANSMISSION
AVIATION EQUIPMENT
COMPATIBLE CONNECTORS
SMA,SMB,SMC,MCX,MMCX
N,FME,TNC,BNC
MINI-UHF,UHF,F,ETC.
FAKRA,GT5.U.FL.W.FL.H.FL.SGC.IPEX
COMPATIBLE CABLES
IMPEDANCE 50Ω/75Ω/93Ω
RG405/U, RG402/U, RG316/U, RG223/U
RG188/U, RG179/U, RG174/U, RG142/U
RG141/U, RG59/U, RG58/U, RG8/U, RG6/U
LMR100,LMR400,SF141J


Ordering information:

Part number

Connector

Cable

Length of cable

TOP-TNC-C01

TNC-SMA(M)

RG58U

10cm or customized

TOP-TNC-C02

TNC-SMA(F)

RG174

10cm or customized

TOP-TNC-C03

TNC-MMCX(M)straight plug

RG174

10cm or customized

TOP-TNC-C04

TNC-MMCX(M)right angle plug

RG178

10cm or customized

TOP-TNC-C05

 TNC-MMCX(RA)

RG316

10cm or customized

TOP-TNC-C06

TNC-open end(without welds)

RG316

10cm or customized

TOP-TNC-C07

TNC-IPEX

1.13/1.37

10cm or customized

TOP-TNC-C08

 TNC-U.FL

0.81/1.13

10cm or customized

TOP-TNC-C09

TNC-MCX(male)

RG316

10cm or customized

Notice:

1. the connector at the end can be customized.

2. the cable also can be made by others, customzied








Key feature:

1. Connector : TNC Female to MCX ( Connectors could be customized , etc .)

2. Cable Type : Black RG174 ( Could be customized , like RG178 ,RG316 , LMR Cable , RG58 Cable, etc ; depends on your requirements .)

3. Cable Length : 20cm ( could be customized , like 50cm ,1 meter , 5 meters , 10meters , etc .)





Cable Type(Name)

BNC male  RG316 cable

Cable Length

100mm (Customized Length Available)

Operating Frequency

DC0-3GHz

VSWR

≤1.20 @DC-3GHz

Durability

≥500 cycles

Waterproof Rate

IP68

Operating Temperature

45 °C-85  °C

Parts Name

Material

Plating

Body

Brass

Ni

Insulator

PTFE

Inner Conductor

Phosphor Bronze

Au

Coupling Nut

Brass

Ni

Ferule

Annealed Copper

Ni

Bandwidth                        100MHZ




Application:

  • configurations for broad compatibility with commercial RF and consumer electronics applications.
  • WiMAX
  • IBurst
  • Zigbee®
  • Bluetooth Wireless®
  • MIMO
  • IEEE 802.11 a/b/g/n
  • Wi-Fi
  • WLAN
  • Wireless Ethernet
  • RFID
  • UWB
  • GSM,GPRS,CDMA,GPS antennas and Adaptor


Brass Antenna Jump Pigtail RF Coaxial Cable with TNC Connector 0






Our  Cable :
---Powerful R&D team
---Wonderful design solution
---Perfect after-sales service
---Strict quality testing
---Rich cooperation experiences with Communication product manufactures
---Competitive price


FAQ
 1. What's the Warranty of the Products?
Answer: In general, all goods with 12 month-warranty after the shipments .

2.  How about the defective rate ?
Answer: Less than 1%.

 3. Where can customers get the Product Specification and other datasheets?
Answer: we will send them via email once get the request from the customers.
