282105-1 3 Position 5.0mm Pitch Wire-to-Board Header Vertical Through Hole Shrouded Friction Lock Polarized 9A Rating for Power Supplies and Industrial Controls

282105-1 3 Position 5.0mm Pitch Wire-to-Board Header Vertical Through Hole Shrouded Friction Lock Polarized 9A Rating for Power Supplies and Industrial Controls

Features

• 3 positions with 5.0mm centerline spacing

• Vertical header orientation with through-hole termination

• Shrouded design for contact protection and alignment

• Friction lock for secure mating retention

• Polarized housing to prevent mis-mating

• Current rating: 9A per contact

• Voltage rating: 250V AC

• Operating temperature range: -25°C to +105°C

• Housing material: UL 94V-0 rated nylon

• Tin-plated brass contacts for reliable conductivity

Applications

• Power supplies and power distribution systems

• Industrial control equipment and automation

• Consumer appliances and white goods

• Automotive electronics and wire harnesses

• HVAC systems and heating controls

• Lighting fixtures and LED drivers

• Battery management and charging systems

• General-purpose higher power wire-to-board connections

Description

The 282105-1 is a 3-position, 5.0mm pitch wire-to-board header from TE Connectivity (formerly AMP), part of the Economy Power (EP) series. It features a vertical, through-hole mounting configuration with a shrouded design for secure mating with EP series receptacle housings. The header includes a friction lock mechanism for reliable retention and is polarized to prevent incorrect mating, making it suitable for higher power applications
