2SD1781KT146R 2A 160V NPN Transistor with High hFE 120-240 625mW Power Low Noise Built-in Diode SOT-89-3 Package Halogen-Free Tape & Reel Packaging
Features
1)Very low VCE(sat). VCE(sat)=0.1V(Typ.) (IC/IB=500mA/50mA)
2)Higt current capacity in compact package.
3)Complements the 2SB1197K.
Applications
Power Supply Control Circuits
Audio Frequency Amplification
Driver Stages for Motors and Relays
Voltage Regulation and Line Drivers
General-Purpose Switching and Amplification
Description
The 2SD1781KT146R is a high-voltage, medium-power NPN bipolar junction transistor (BJT) designed for general-purpose amplification and switching applications. Encapsulated in a compact SOT-89-3 surface-mount package, it offers a robust combination of voltage tolerance, current gain, and power handling capability.
