Features

1:Component Type: High-frequency multilayer ceramic inductor.

2:Inductance Value: 2.7 nH. This is a relatively small inductance value, making it highly suitable for high-frequency signal processing and data transmission circuits.

3:Size: 0201 package. Its footprint is only 0.6mm x 0.3mm, making it one of the smallest standard packages in the industry. This ultra-compact volume makes it ideal for high-density mounting on PCBs, such as in smartphones, wearable devices, and RF modules.

4:Tolerance: ±0.1 nH. High precision ensures consistent and stable circuit performance, which is crucial for RF circuits requiring precise impedance matching.

5:Rated Current: Despite its small size, it can handle a certain amount of current. Typically, its saturation current is on the order of several hundred mA (refer to the datasheet for specifics), sufficient for most small-signal RF applications.

6:Q Factor: High Q value. At the target operating frequency, this component exhibits a very high Quality Factor, meaning its inductive reactance is significantly greater than its resistive losses. This is a critical characteristic for RF applications requiring low insertion loss and high efficiency, such as filters and matching networks.

7:Self-Resonant Frequency: High SRF. Its self-resonant frequency is typically in the high GHz range, ensuring stable performance as a pure inductor within the target operating frequency band.

8:DC Resistance: Low DCR. It features a very low DC resistance, helping to reduce power loss and heat generation.

9:Reliability: Utilizes a ceramic construction, providing good mechanical strength and heat resistance. The component typically conforms to the AEC-Q200 standard, indicating its suitability for demanding automotive electronics and industrial applications.

10:Packaging: Supplied in tape and reel packaging, fully compatible with automated SMT production lines, suitable for large-scale, high-efficiency manufacturing processes.

Applications

• Power equipment: Products that can be used in power equipment such as renewable energy equipment, energy storage equipment and EV charging equipment and whose functions are not directly related to the protection of human life and property.

• Industrial equipment: Products that can be used in industrial equipment such as base stations, manufacturing equipment, industrial robotics equipment, and measurement equipment, and whose functions do not directly relate to the protection of human life and property.

• Medical equipment (GHTF Class C) *Except for implant/surgery/auto injector: Products that can be used for medical equipment of Class C of the international classification class GHTF and whose malfunction is considered to pose a relatively high risk to the human body.

• Medical equipment (GHTF Class A and B): Products that can be used for medical equipment regulated by Class A and Class B of the international classification class GHTF and whose functions do not directly relate to the protection of human life and property.

• Consumer equipment: Products that can be used in consumer equipment such as home appliances, audio/visual equipment, communication equipment, information equipment, office equipment, and household robotics, and whose functions are not directly related to the protection of human life and property.

Description

LQP03TN2N7B02D is an ultra-miniature, high-frequency, high-Q multilayer ceramic inductor manufactured by Murata Manufacturing Co., Ltd., belonging to its LQP03T series. It is specifically designed for modern electronic circuits with extreme demands for space and performance.
