Features

Power-On Reset Generator with Adjustable Delay Time:1.25ms to 10s.

Very Low Quiescent Current: 2.8andmu;A Typical

High Threshold Accuracy: 0.5% Typ.

Fixed Threshold Voltages for Standard Voltage Railsfrom 0.9V to 5V and Adjustable Voltage Down to 0.4Vare available.

Manual Reset ( MR ) Input.

Open-Drain RESET Output.

Temperature Range: -40anddeg;C to +125anddeg;C

Packaging (Pb-free andamp; Green):

andnbsp;andnbsp;andquot;6-pins, TDFN 2.0x2.0(ZC)
andnbsp; andquot;6-pins, SOT23 (TA)

Totally Lead-Free andamp; Fully RoHS Compliant

Halogen and Antimony Free.andnbsp;

andnbsp;

Application

DSP or Microcontroller Applications Capacitor

Notebook/Desktop Computers

PDAs/Hand-Held Products Battery-poweredApplications

Portable/Battery-Powered Products

FPGA/ASIC Applications

andnbsp;

Description

The PT7M3808G family of microprocessor supervisoryandnbsp;circuits monitor system voltage from 0.4V to 5.0V, assertingandnbsp;an open-drain RESETsignal when the SENSE voltageandnbsp;drops below a preset threshold or when the manual resetandnbsp;(MR )pin drops to a logic low. The RESET outputandnbsp;remains low for the user-adjustable delay time after theandnbsp;SENSE voltage and manual reset ( MR )return above theandnbsp;respective thresholds.

The PT7M3808G series uses a precision reference to achieveandnbsp;0.5% threshold accuracy for VIT s3.3 V. The reset delayandnbsp;time can be set to 20ms by disconnecting the Cr pin, 300msandnbsp;by connecting the C+ pin to Vop using a resister, or can beandnbsp;user-adjusted between 1.25ms and 10s by connecting the Candnbsp;pin to an external capacitor. The PT7M3808 has a very lowandnbsp;typical quiescent current of 2.8uA so it is well-suited toandnbsp;battery-powered applications.It is available in a smallandnbsp;SOT23 and an ultra-small 2.0x2.0 TDFN package, and isandnbsp;fully specified over a temperature range of -40anddeg;C to +125anddeg;C.
