Features

3.5V to 60V Input Voltage Range

200-mandOmega; High-Side MOSFET

High Efficiency at Light Loads with a PulseSkipping Eco-Modeandtrade;

Tighter Enable Threshold than TPS54060for More Accurate UVLO Voltage

Adjustable UVLO Voltage and Hysteresis

116andmu;A Operating Quiescent Current

1.3andmu;A Shutdown Current

100kHz to 2.5MHz Switching Frequency

Synchronizes to External Clock

Adjustable Slow Start/Sequencing

UV and OV Power Good Output

0.8-V Internal Voltage Reference

MSOP.10 and 3mm x 3mm VSON-10 PackageWith PowerPADandtrade;

andnbsp;

Applications

12-V,24-V and 48-V Industrial and Commerciaandnbsp;Low Power Systems

Aftermarket Auto Accessories:Video,GPSEntertainment

andnbsp;

Description

The TPS54060A device is a 60V,0.5A,step downandnbsp;regulator with an integrated high side MOSFET.Current mode control provides simple externalandnbsp;compensation and flexible component selection.Aandnbsp;low ripple pulse skip mode reduces the no load,andnbsp;regulated output supply current to 116andmu;A. Using theandnbsp;enable pin,shutdown supply current is reduced toandnbsp;1.3uA, when the enable pin is low.

Under voltage lockout is internally set at 2.5V, butandnbsp;can be increased using the enable pin. The outputandnbsp;voltage startup ramp is controlled by the slow startandnbsp;pin that canandnbsp;also be configuredandnbsp;forandnbsp;sequencing/tracking. An open drain power goodandnbsp;signal indicates the output is within 94% to 107% ofandnbsp;its nominal voltage.

A wide switching frequency range allows efficiencyandnbsp;and externalcomponentsize to beoptimized.Frequency fold back and thermal shutdown protectsandnbsp;the part during an overload condition.
