Features

 Current transfer ratio

  (CTR: minimum 50% at IF = 5 mA, VCE = 5V)

 High input-output isolation voltage

  (Viso = 3750 Vrms)

 High collector-emitter voltage

  (VCEO = 80V)

 Response time

  (tr: typical, 4 μs at VCE = 2V, IC = 2 mA, RL = 100Ω)

 Mini-flat package (2.0-mm profile) in tape and reel package

 UL approved

 CSA approved

 IEC 60747-5-5 approved

 Options available:

  – IEC 60747-5-5 approvals (060)

Applications

 I/O interfaces for computers

 System appliances, measuring instruments

 Signal transmission between circuits of different potentials and impedances

 Feedback circuit in power supply

Description

The Broadcom® HCPL-181 contains a light-emitting diode optically coupled to a phototransistor. It is packaged in a 4-pin mini-flat SMD package with a 2.0-mm profile. The small dimension of this product allows significant space saving. The package volume is 30% smaller than that of conventional DIP type. Input-output isolation voltage is 3750 Vrms. Response time, tr, is typically 4 μs and minimum CTR is 50% at input current of 5 mA.
