Features

andbull; For a newer drop-in alternative, see the TLV1117

andbull; For drop-in replacements in fixed output SOT-223 package configuration and improved functionality, see the TLV761

andbull; Available in 1.8 V, 2.5 V, 3.3 V, 5 V, and adjustable versions

andbull; Space-saving SOT-223 and WSON packages

andbull; Current limiting and thermal protection

andbull; Output current: 800 mA

andbull; Line regulation: 0.2% (maximum)

andbull; Load regulation: 0.4% (maximum)

andbull; Temperature range:

andnbsp; andndash; LM1117: 0anddeg;C to +125anddeg;C

andnbsp; andndash; LM1117I: andndash;40anddeg;C to +125anddeg;C

andnbsp;

Applications

andbull; AC drive power stage modules

andbull; Merchant network and server PSU

andbull; Industrial AC/DC

andbull; Ultrasound scanners

andbull; Servo drive control modules

andnbsp;

Description

The LM1117 is a low dropout voltage regulator with a dropout of 1.2 V at 800 mA of load current.

The LM1117 is available in an adjustable version, which can set the output voltage from 1.25 V to 13.8 V with only two external resistors. In addition, the device is available in five fixed voltages, 1.8 V, 2.5 V, 3.3 V, and 5 V.

The LM1117 offers current limiting and thermal shutdown. The circuit includes a Zener trimmed band gap reference to assure output voltage accuracy to within andplusmn;1%.

A minimum of 10-andmicro;F tantalum capacitor is required at the output to improve the transient response and stability.
