Features

andbull; Complete Unipolar High-Side Current Measurement Circuit

andbull; WideSupply and Common-Mode Range

andbull; INA139: 2.7 V to 40 V

andbull; INA169: 2.7 V to 60 V

andbull; Independent Supply and Input Common-Mode Voltages

andbull; Single Resistor Gain Set

andbull; LowQuiescent Current: 60 andmicro;A (Typical)

andbull; 5-Pin, SOT-23 Packages

andnbsp;

Applications

andbull; Current Shunt Measurement:

andnbsp; andndash; Automotive, Telephone, Computers

andbull; Portable and Battery-Backup Systems

andbull; Battery Chargers

andbull; Power Management

andbull; Cell Phones

andbull; Precision Current Source

andnbsp;

Description

The INA139 and INA169 are high-side, unipolar, current shunt monitors. Wide input common-mode voltage range, high-speed, low quiescent current, and tiny SOT-23 packaging enable use in a variety of applications.

Input common-mode and power-supply voltages are independent and can range from 2.7 V to 40 V for the INA139 and 2.7 V to 60 V for the INA169. Quiescent current is only 60 andmicro;A, which permits connecting the power supply to either side of the current measurement shunt with minimal error.

The device converts a differential input voltage to a current output. This current is converted back to a voltage with an external load resistor that sets any gain from 1 to over 100. Although designed for current shunt measurement, the circuit invites creative applications in measurement and level shifting.

Both the INA139 and INA169 are available in 5-pin SOT-23 packages. The INA139 device is specified for theandndash;40anddeg;C to +125anddeg;C temperature range, and the INA169 is specified fromandndash;40anddeg;C to +85anddeg;C.
