ESD5Z3.3T1G 3.3V Clamping SOD-523 Package <1pF Capacitance Bi-Directional IEC 61000-4-2 Level 4 (30kV), ESD Protection High-Speed Data Line Defense Ideal for Portable Electronics

ESD5Z3.3T1G 3.3V Clamping SOD-523 Package <1pF Capacitance Bi-Directional IEC 61000-4-2 Level 4 (30kV), ESD Protection High-Speed Data Line Defense Ideal for Portable Electronics

Features

 Low Clamping Voltage

 Small Body Outline Dimensions: 0.047 x 0.032 (1.20 mm x 0.80 mm)

 Low Body Height: 0.028 (0.7 mm)

 Stand−off Voltage: 2.5 V − 12 V

 Peak Power up to 240 Watts @ 8 x 20 s Pulse

 Low Leakage

 Response Time is Typically < 1 ns

 ESD Rating of Class 3 (> 16 kV) per Human Body Model

 IEC61000−4−2 Level 4 ESD Protection

 IEC61000−4−4 Level 4 EFT Protection

 SZ Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC−Q101 Qualified and PPAP Capable

 These Devices are Pb−Free and are RoHS Compliant

Applications

High-Speed Data Interface & Port Protection: This is its core application. It is ideal for protecting:USB 3.0/3.1/Type-C:

High-speed data lines are extremely sensitive to capacitance; the device's ultra-low capacitance ensures signal integrity.

HDMI and DisplayPort: Protects high-definition video interfaces from Electrostatic Discharge (ESD) strikes.

I/O Ports on Mobile Devices (smartphones, tablets): Such as headphone jacks, buttons, and charging ports.

Portable/Consumer Electronics: Due to its tiny SOD-523 package and highly efficient protection capability, it is perfectly suited for space-constrained designs:

Smartphones, tablets, digital cameras, wearable devices (smartwatches, fitness trackers).

Laptops, Bluetooth headsets, portable gaming consoles.

Communication Equipment: Protects high-speed communication lines, for example:

LAN ports on network switches and routers.

Radio Frequency (RF) antenna modules.

Description

The ESD5Z Series is designed to protect voltage sensitive components from ESD and transient voltage events. Excellent clamping capability, low leakage, and fast response time, make these parts ideal for ESD protection on designs where board space is at a premium. Because of its small size, it is suited for use in cellular phones, portable devices, digital cameras, power supplies and many other portable applications.
