SN74LVC1G07 Single Buffered Open-Drain Gate 1.65V to 5.5V Wide VCC 32mA Output Low Power SOT-23-5 Tiny and Efficient Solution

SN74LVC1G07 Single Buffered Open-Drain Gate 1.65V to 5.5V Wide VCC 32mA Output Low Power SOT-23-5 Tiny andamp; Efficient Solution

andnbsp;

Features

andbull; Available in the ultra small 0.64mm2 package (DPW) with 0.5mm pitch

andbull; Supports 5V VCC operation

andbull; Input and open-drain output accept voltages up to 5.5V

andbull; Can translate up or down

andbull; Maximum tpd of 4.2ns at 3.3V

andbull; Low power consumption, 10andmicro;A maximum ICC

andbull; andplusmn;24mA output drive at 3.3V

andbull; Ioff supports live insertion, partial-power-down mode, and back-drive protection

andbull; Latch-up performance exceeds 100mA per JESD 78, Class II

andbull; ESD protection exceeds JESD 22

andnbsp; andndash; 2000V Human-body model (A114-A)

andnbsp; andndash; 200V Machine model (A115-A)

andnbsp; andndash; 1000V Charged-device model (C101)

andnbsp;

Applications

andbull; AV receiver

andbull; Blu-ray player and home theater

andbull; DVD recorder and player

andbull; Desktop or notebook PC

andbull; Digital radio or internet radio player

andbull; Digital Video Camera (DVC)

andbull; Embedded PC

andbull; GPS: personal navigation device

andbull; Mobile internet device

andbull; Network projector front end

andbull; Portable media player

andbull; Pro audio mixer

andbull; Smoke detector

andbull; Solid State Drive (SSD): enterprise

andbull; High-definition (HDTV)

andbull; Tablet: enterprise

andbull; Audio dock: portable

andbull; DLP front projection system

andbull; DVR and DVS

andbull; Digital Picture Frame (DPF)

andbull; Digital still camera

andnbsp;

Description

This single buffer/driver is designed for 1.65V to 5.5V VCC operation.

The output of the SN74LVC1G07 device is open drain and can be connected to other open-drain outputs to implement active-low wired-OR or active-high wired AND functions. The maximum sink current is 32mA.

The SN74LVC1G07 is available in a variety of packages, including the ultra-small DPW package with a body size of 0.8mm andtimes; 0.8mm.
