MMSZ5234BS-7-F Zener Diode 5.6V 0.5W Stabilization SOD-323 Package ±5% Tolerance 10mA Regulator Surge Protection SMT Miniature Size Automotive Grade Tape and Reel Packaging

Product Attributes

Attribute	Value
Function	Step-Up, Step-Down
Output Configuration	Positive or Negative
Topology	Buck, Boost
Output Type	Adjustable
Number of Outputs	1

Features

Planar Die Construction
Small Surface Mount Package
General Purpose
Ideally Suited for Automated Assembly Processes
Totally Lead-Free and Fully RoHS Compliant (Notes 1 and 2)
Halogen and Antimony Free. "Green" Device (Note 3)

Applications

Voltage Clamping and Over-Voltage Protection: Widely used to protect sensitive input pins (e.g., MCUs, MOSFET gates) from ESD, surges, or voltage spikes by clamping voltages above 5.6V to a safe level.
Low-Drop Voltage Regulation: Acts as a low-cost regulator in low-current (andlt;10mA) circuits, providing a stable 5.6V reference voltage.
Level Shifting and Signal Conditioning: Used in communication interfaces (e.g., UART, I2C) to restrict signal levels within safe ranges.
Automotive Electronics: Suitable for 12V automotive systems (e.g., body control modules, infotainment) to protect against load dump surges, meeting automotive-grade standards.
Portable Consumer Electronics: Ideal for space-constrained devices like smartphones, TWS earphones, and tablets due to its miniature SOD-323 package, providing ESD protection for batteries, USB ports, or key circuits.

Description

• Case: SOD323

• Case Material: Molded Plastic. UL Flammability Classification Rating 94V-0

• Moisture Sensitivity: Level 1 per J-STD-020D

• Terminals: Solderable per MIL-STD-202, Method 208

• Lead Free Plating (Matte Tin Finish annealed over Alloy 42 leadframe). Polarity: Cathode Band

• Weight: 0.004 grams (approximate)

Information

Category	Discrete Semiconductor Products Diodes Zener Single Zener Diodes
Mfr	Diodes Incorporated
Series	-
Packaging	Tape and Reel (TR) Cut Tape (CT) Digi-Reel®
Part Status	Active
Voltage - Zener (Nom) (Vz)	6.2 V
Tolerance	±5%
Power - Max	200 mW
Impedance (Max) (Zzt)	7 Ohms
Current - Reverse Leakage @ Vr	5 µA @ 4 V
Voltage - Forward (Vf) (Max) @ If	900 mV @ 10 mA
Operating Temperature	-65°C ~ 150°C
Mounting Type	Surface Mount
Package / Case	SC-76, SOD-323
Supplier Device Package	SOD-323
Base Product Number	MMSZ5234
