CSD17522Q5A 25V/4.7mΩ NexFET MOSFET with 40A Pulse 1.5V Max VGS(th) AEC-Q101 Qualified SON 5x6mm Package Halogen-Free and Ultra-Low Qg and Qgd
Product Attributes
| Attribute |
Value |
| Function |
Step-Up, Step-Down |
| Output Configuration |
Positive or Negative |
| Topology |
Buck, Boost |
| Output Type |
Adjustable |
| Number of Outputs |
1 |
Product Description
CSD17522Q5A 25V/4.7mΩ NexFET MOSFET with 40A Pulse 1.5V Max VGS(th) AEC-Q101 Qualified SON 5x6mm Package Halogen-Free and Ultra-Low Qg and Qgd
Features
- Optimized for 5V Gate Drive
- Ultralow Qg and Qgd
- Low Thermal Resistance
- Avalanche Rated
- Pb Free Terminal Plating
- RoHS Compliant
- Halogen Free
- SON 5-mm x 6-mm Plastic Package
Applications
Notebook Point of Load
Point-of-Load Synchronous Buck in Networking, Telecom and Computing Systems
Description
The NexFET™ power MOSFET has been designed to minimize losses in power conversion applications, and optimized for 5V gate drive applications.
Technical Specifications
| Category |
Discrete Semiconductor Products Transistors FETs, MOSFETs Single FETs, MOSFETs |
| Mfr |
Texas Instruments |
| Series |
NexFET™ |
| Packaging |
Tape and Reel (TR) Cut Tape (CT) Digi-Reel® |
| Part Status |
Active |
| FET Type |
N-Channel |
| Technology |
MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) |
30 V |
| Current - Continuous Drain (Id) @ 25°C |
87A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) |
4.5V, 10V |
| Rds On (Max) @ Id, Vgs |
8.1mOhm @ 14A, 10V |
| Vgs(th) (Max) @ Id |
2V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs |
4.3 nC @ 4.5 V |
| Vgs (Max) |
±20V |
| Input Capacitance (Ciss) (Max) @ Vds |
695 pF @ 15 V |
| FET Feature |
- |
| Power Dissipation (Max) |
3W (Ta) |
| Operating Temperature |
-55°C ~ 150°C (TJ) |
| Grade |
- |
| Qualification |
- |
| Mounting Type |
Surface Mount |
| Supplier Device Package |
8-VSONP (5x6) |
| Package / Case |
8-PowerTDFN |
| Base Product Number |
CSD17522 |
