TPS26600PWPR 42V/3A eFuse with Ultra-Low IQ ±1.5% OVP Threshold Adjustable Current Limit Power Good Reverse Polarity and Input/Output Protection
Product Attributes
| Attribute |
Value |
| Function |
Step-Up, Step-Down |
| Output Configuration |
Positive or Negative |
| Topology |
Buck, Boost |
| Output Type |
Adjustable |
| Number of Outputs |
1 |
Product Description
The TPS2660x devices are compact, feature rich high voltage eFuses with a full suite of protection features. The wide supply input range of 4.2 to 60 V allows control of many popular DC bus voltages. The device can withstand and protect the loads from positive and negative supply voltages up to ±60 V.
Features
- 4.2-V to 60-V Operating voltage, 62-V absolute maximum
- Integrated reverse input polarity protection down to -60 V - Zero additional components required
- Integrated back to back MOSFETs with 150-mΩ total RON
- 0.1-A to 2.23-A Adjustable current limit (±5% accuracy at 1 A)
- Functional safety capable - Documentation available to aid functional safety system design
- Load protection during Surge (IEC 61000-4-5) with minimum external components
- IMON current indicator output (±8.5% accuracy)
- Low quiescent current, 300-µA in operating, 20-µA in shutdown
- Adjustable UVLO, OVP cut off, output slew rate control
- Reverse current blocking
- Fixed 38-V overvoltage clamp (TPS26602 only)
- Available in easy-to-use 16-Pin HTSSOP and 24 Pin VQFN packages
- Selectable current-limiting fault response options (Auto-Retry, Latch Off, Circuit Breaker Modes)
- UL2367 Recognized - File No. 169910 - RILIM ≥ 5.36 kΩ (2.35-A maximum)
- UL60950 - Safe during single point failure test - Open/Short ILIM detection
Applications
- Programmable logic controller
- Distributed Control System (DCS)
- Control and automation
- Redundant supply ORing
- Industrial surge protection
Additional Information
| Category |
Integrated Circuits (ICs) Power Management (PMIC) Current Regulation/Management |
| Manufacturer |
Texas Instruments |
| Packaging |
Tape and Reel (TR) Cut Tape (CT) Digi-Reel® |
| Part Status |
Active |
| Function |
Electronic Fuse |
| Accuracy |
±5% |
| Voltage - Input |
4.2V ~ 55V |
| Current - Output |
2.35A |
| Operating Temperature |
-40°C ~ 125°C (TJ) |
| Mounting Type |
Surface Mount |
| Package / Case |
16-PowerTSSOP (0.173", 4.40mm Width) |
| Supplier Device Package |
16-HTSSOP |
| Base Product Number |
TPS26600 |
