FeaTures

n Wide VIN Range: 2.7V to 17V

n Wide VOUT Range: 0.6V to VIN

n 95% Max Efficiency

n Low IQ: 3.5µA, Zero-Current Shutdown

n Constant Frequency (1MHz/2.25MHz)

n Fixed VOUT Options Available

n Low Dropout Operation (100% Duty Cycle) with Ultralow IQ

n 2A Rated Output Current

n ±1% Output Voltage Accuracy

n Current Mode Operation for Excellent Line and Load Transient Response

n Synchronizable to External Clock

n Pulse-Skipping, Forced Continuous, Burst Mode® Operation

n Internal Compensation and Soft-Start

n Overtemperature Protection

n Compact 8-Lead DFN (3mm × 3mm) Package

applicaTions

n Battery Powered Equipment

n Portable Instrumentation

n Emergency Radios

n General Purpose Step-Down Supplies

DescripTion

The LTC®3624/LTC3624-2 is a high efficiency 17V, 2A synchronous monolithic step-down regulator. The switch ing frequency is fixed to 1MHz (LTC3624) or 2.25MHz (LTC3624-2) with a ±40% synchronization range. The regulator features ultralow quiescent current and high efficiency over a wide VOUT range.

The step-down regulator operates from an input voltage range of 2.7V to 17V and provides an adjustable output range from 0.6V to VIN while delivering up to 2A of output current. A user-selectable mode input is provided to allow the user to trade off ripple noise for light load efficiency; Burst Mode operation provides the highest efficiency at light loads, while pulse-skipping mode provides the lowest voltage ripple. The MODE pin can also be used to sync the switching frequency to an external clock.
