LM25119PSQ/NOPB Buck Controller 4.5-42V Input 100V/10A MOSFET Drive 200kHz-1MHz Freq Sync Rect Adjustable UVLO Thermal Protection 16-WQFN, -40°C to +125°C

LM25119PSQ/NOPB Buck Controller 4.5-42V Input 100V/10A MOSFET Drive 200kHz-1MHz Freq Sync Rect Adjustable UVLO Thermal Protection 16-WQFN, -40°C to +125°C

Features

• Emulated Peak Current Mode Control

• WideOperating Range (4.5 V to 42 V)

• Easily Configurable for Dual Outputs or Interleaved Single Output

• Robust 3.3-A Peak Gate Drive

• Switching Frequency Programmable to 750 kHz

• Optional Diode Emulation Mode

• Programmable Output From 0.8 V

• Precision 1.5% Voltage Reference

• Programmable Current Limit

• Hiccup Mode Overload Protection

• Programmable Soft-Start

• Programmable Line Undervoltage Lockout

• Automatic Switchover to External Bias Supply

• Channel2 Enable Logic Input

• Thermal Shutdown

• Leadless 32-Pin WQFN Package

Applications

• Industrial DC-DC Motor Drivers

• Telecom Servers and Routers

Description

The LM25119 device is a dual synchronous buck controller intended for step-down regulator applications from a high voltage or widely varying input supply. The control method is based upon current mode control using an emulated current ramp. Current mode control provides inherent line feedforward, cycle-by-cycle current limiting and ease of-loop compensation. The use of an emulated control ramp reduces noise sensitivity of the pulse width modulation circuit, allowing reliable control of very small duty cycles necessary in high input voltage applications. The switching frequency is programmable from 50 kHz to 750 kHz. The LM25119 device drives external high-side and low side N-channel MOS power switches with adaptive dead-time control. A user-selectable diode emulation mode enables discontinuous mode operation for improved efficiency at light load conditions. A high voltage bias regulator with automatic switch-over to external bias further improves efficiency. Additional features include thermal shutdown, frequency synchronization, cycle-by-cycle and hiccup mode current limit and adjustable line undervoltage lockout. The device is available in a power enhanced leadless 32-pin WQFN package featuring an exposed die attach pad to aid thermal dissipation.

INFORMATION

Drawing

Our advantage :

• High quality products --- our offers are 100% new and original, ROHS
• Competitive price --- good Purchase channels with good price.
• Professional service --- strict quality testing before the shipment, and perfect after-sales service after the purchase.
• Adequate inventory --- With the support of our strong Purchasing team,
• Fast delivery --- we will ship the goods within 1-3 working days after the payment confirmed.

be sure to meet your need for all kinds of components. ^_^


Product List
Supply a Series of Electronic Components, full range of semiconductors, active & passive Components.We can help you to get all for bom of the PCB,IN a word, you can get one-stop solution here,


The offers including:
Integrated Circuit, Memory ICs, Diode, Transistor , Capacitor, Resistor, Varistor, Fuse, Trimmer & Potentiometer, Transformer, Battery, Cable, Relay, Switch, Connector, Terminal Block, Crystal & Oscillator, Inductor, Sensor, Transformer, IGBT Driver, LED,LCD, Convertor, PCB (Printed Circuit Board),PCBA (PCB Assembly)

Strong in Brand:
Microchip, MAX, AD, TI, ATMEL, ST, ON, NS, Intersil, Winbond, Vishay, ISSI, Infineon, NEC, FAIRCHILD, OMRON,YAGEO, TDK, etc
