CSD17309Q3 30V N-Channel NexFET™ MOSFET with 3.6mΩ RDS(on) 40A Continuous Current 175°C Rating Ultra-Low Qg 3mm×3mm SON Package AEC-Q101 Qualified and Pb-Free

Large Image : CSD17309Q3 30V N-Channel NexFET™ MOSFET with 3.6mΩ RDS(on) 40A Continuous Current 175°C Rating Ultra-Low Qg 3mm×3mm SON Package AEC-Q101 Qualified and Pb-Free

Product Details:

Place of Origin:	China
Brand Name:	Texas Instruments
Certification:	CE, GCF, ROHS
Model Number:	CSD17309Q3

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	Packed in original tray firstly ,then carton, at last Bubble bag for outer packing
Delivery Time:	3-5 working days after received the payment
Payment Terms:	T/T, Western Union,
Supply Ability:	1000pcs per month

Contact Now

Detailed Product Description

Function:	Step-Up, Step-Down	Output Configuration:	Positive Or Negative
Topology:	Buck, Boost	Output Type:	Adjustable
Number Of Outputs:	1
Highlight:	30V N-Channel MOSFET with 3.6mΩ RDS(on) , AEC-Q101 qualified NexFET™ MOSFET , 3mm×3mm SON package MOSFET

CSD17309Q3 30V N-Channel NexFETandtrade; MOSFET with 3.6mandOmega; RDS(on) 40A Continuous Current 175anddeg;C Rating Ultra-Low Qg 3mmandtimes;3mm SON Package AEC-Q101 Qualified andamp; Pb-Free

andnbsp;

Featuresandnbsp;

andbull; Optimizedfor5VGateDrive

andbull; Ultra-LowQgandQgd

andbull; LowThermalResistance

andbull; AvalancheRated

andbull; PbFreeTerminalPlating

andbull; RoHSCompliant

andbull; HalogenFree

andbull; SON3.3mmandtimes;3.3mmPlasticPackage

andnbsp;

Applications

andbull; NotebookPointofLoad

andbull; PointofLoadSynchronousBuckinNetworking,

andnbsp;andnbsp; Telecom,andComputingSystems

andnbsp;

Description

This 30 V,4.2 m NexFET power MOSFET is designed to minimize losses in power conversion applications;and optimized for5Vgate drive applications.

andnbsp;

INFORMATION

Category	Discrete Semiconductor Products Transistors FETs, MOSFETs Single FETs, MOSFETs	andnbsp;
Mfr	Texas Instruments	andnbsp;
Series	NexFETandtrade;	andnbsp;
Packaging	Tape andamp; Reel (TR) Cut Tape (CT) Digi-Reelandreg;	andnbsp; andnbsp; andnbsp;
Part Status	Active	andnbsp;
FET Type	N-Channel	andnbsp;
Technology	MOSFET (Metal Oxide)	andnbsp;
Drain to Source Voltage (Vdss)	30 V	andnbsp;
Current - Continuous Drain (Id) @ 25anddeg;C	20A (Ta), 60A (Tc)	andnbsp;
Drive Voltage (Max Rds On, Min Rds On)	3V, 8V	andnbsp;
Rds On (Max) @ Id, Vgs	5.4mOhm @ 18A, 8V	andnbsp;
Vgs(th) (Max) @ Id	1.7V @ 250andmicro;A	andnbsp;
Gate Charge (Qg) (Max) @ Vgs	10 nC @ 4.5 V	andnbsp;
Vgs (Max)	+10V, -8V	andnbsp;
Input Capacitance (Ciss) (Max) @ Vds	1440 pF @ 15 V	andnbsp;
FET Feature	-	andnbsp;
Power Dissipation (Max)	2.8W (Ta)	andnbsp;
Operating Temperature	-55anddeg;C ~ 150anddeg;C (TJ)	andnbsp;
Grade	-	andnbsp;
Qualification	-	andnbsp;
Mounting Type	Surface Mount	andnbsp;
Supplier Device Package	8-VSON-CLIP (3.3x3.3)	andnbsp;
Package / Case	8-PowerTDFN	andnbsp;
Base Product Number	CSD17309
