FEATURES

◯Chip common mode filter for large current applications.

◯For each series, there is excellent common mode impedance and noise suppression in a compact case.

◯Low profile and small size makes it optimal for surface mounting.

◯Operating temperature range: -40 to +85°C

APPLICATION

◯Power line noise countermeasure for electronic equipment (DVCs, DVD cams, DSCs, etc.).

Description

◯The storage period is within 12 months. Be sure to follow the storage conditions (temperature: 5 to 40°C, humidity: 10 to 75% RH or less). If the storage period elapses, the soldering of the terminal electrodes may deteriorate.

◯Do not use or store in locations where there are conditions such as gas corrosion (salt, acid, alkali, etc.).

◯Soldering corrections after mounting should be within the range of the conditions determined in the specifications. If overheated, a short circuit, performance deterioration, or lifespan shortening may occur.

◯When embedding a printed circuit board where a chip is mounted to a set, be sure that residual stress is not given to the chip due to the overall distortion of the printed circuit board and partial distortion such as at screw tightening portions.

◯Self heating (temperature increase) occurs when the power is turned ON, so the tolerance should be sufficient for the set thermal design.

◯Carefully lay out the coil for the circuit board design of the non-magnetic shield type. A malfunction may occur due to magnetic interference.

◯Use a wrist band to discharge static electricity in your body through the grounding wire.

◯Do not expose the products to magnets or magnetic fields.
