Features

 • InputVoltageRange:2.0Vto16V

• OutputVoltageRange:2.5Vto9V

• Upto95%Efficiency

• +/-1%dcaccuracyinPWMmode

• +3%/-1%dcaccuracyinPFMmode

• 2AOutputCurrent inBuckMode

• 2AOutputCurrent inBoostMode (VIN=4V;Vout=5V)

• PreciseENABLEinputallows–userdefinedundervoltagelockout–exactsequencing

• AutomaticTransitionBetweenStepDownand BoostMode

• TypicalDeviceQuiescentCurrent:50μA

• FixedandAdjustableOutputVoltageOptions

• OutputDischargeOption

• PowerSaveModeforImprovedEfficiencyatLow OutputPower

• ForcedFixedFrequencyOperationat2.4MHz andSynchronizationOption

• PowerGoodOutput

• VSELsimplyallowsoutputvoltagechange

• LoadDisconnectDuringShutdown

• OvertemperatureProtection

• Input /OutputOvervoltageProtection

• AvailableinQFNPackage

Applications

• DualLi-IonApplications

• IndustrialMeteringEquipment

• DSC'sandCamcorders

• NotebookComputers

• UltraMobilePC'sandMobileInternetDevices

• PersonalMedicalProducts

Description

The TPS6307x is a high efficiency, lowquiescent currentbuck-boostconvertersuitableforapplications wherethe input voltagecanbehigheror lower than theoutputvoltage.Outputcurrentscangoashighas 2Ainboostmodeandinbuckmode.Thebuck-boost converter isbasedonafixedfrequency,pulse-width modulation (PWM) controller using synchronous rectificationtoobtainmaximumefficiency.At lowload currents, theconverter entersPowerSaveMode to maintain high efficiency over a wide load current range. The converter can be disabled tominimize battery drain. During shutdown, the load is disconnectedfromthebattery.Thedeviceisavailable ina2.5mmx3mmQFNpackage.
