LMD18200T 3A H-Bridge Motor Driver 55V Max PWM Control Thermal Protection Low RDS(on) TTL/CMOS Compatible SOIC-15 Package - Ideal for Robotics and Motion Control

LMD18200T 3A H-Bridge Motor Driver 55V Max PWM Control Thermal Protection Low RDS(on) TTL/CMOS Compatible SOIC-15 Package - Ideal for Robotics andamp; Motion Control

andnbsp;

FEATURES

andnbsp;andbull; Delivers Up to 3A Continuous Output

andbull; Operates at Supply Voltages Up to 55V

andbull; LowRDS(ON) Typically 0.33andOmega; per Switch at 3A

andbull; TTLandCMOSCompatible Inputs

andbull; Noandldquo;Shoot-Throughandrdquo; Current

andbull; Thermal Warning Flag Output at 145anddeg;C

andbull; Thermal Shutdown (Outputs Off) at 170anddeg;C

andbull; Internal Clamp Diodes

andbull; Shorted Load Protection

andbull; Internal Charge Pump with External Bootstrap Capability

andnbsp;

APPLICATIONS

andbull; DCandStepper Motor Drives

andbull; Position and Velocity Servomechanisms

andbull; Factory Automation Robots

andbull; Numerically Controlled Machinery

andbull; Computer Printers and Plotters

andnbsp;

DESCRIPTION

The LMD18200 is a 3A H-Bridge designed for motion control applications. The device is built using a multi technology process which combines bipolar and CMOS control circuitry with DMOS power devices on the same monolithic structure. Ideal for driving DC and stepper motors; the LMD18200 accommodates peak output currents up to 6A. An innovative circuit which facilitates low-loss sensing of the output current has been implemented.
