MCIMX6U5EVM10AC i.MX 6UltraLite ARM Cortex-A7 MPU 528MHz 128KB L2 Cache 10/100 Ethernet 2x USB 2.0 8x UART Secure Boot Industrial Temp (-40°C to +105°C) Low Power Design

MCIMX6U5EVM10AC i.MX 6UltraLite ARM Cortex-A7 MPU @ 528MHz 128KB L2 Cache 10/100 Ethernet 2x USB 2.0 8x UART Secure Boot Industrial Temp (-40anddeg;C to +105anddeg;C) Low Power Design

andnbsp;

Features

The i.MX 6Solo/6DualLite processors are based on Arm Cortex-A9 MPCore Platform, which has the following features:

andbull; The i.MX 6Solo supports single Arm Cortex-A9 MPCore (with TrustZone)

andbull; The i.MX 6DualLite supports dual Arm Cortex-A9 MPCore (with TrustZone)

andbull; The core configuration is symmetric, where each core includes:

andmdash; 32 KByte L1 Instruction Cache

andmdash; 32 KByte L1 Data Cache

andmdash; Private Timer and Watchdog

andmdash; Cortex-A9 NEON MPE (Media Processing Engine) Co-processor

The Arm Cortex-A9 MPCore complex includes:

andbull; General Interrupt Controller (GIC) with 128 interrupt support

andbull; Global Timer

andbull; Snoop Control Unit (SCU)

andbull; 512 KB unified I/D L2 cache:

andmdash; Used by one core in i.MX 6Solo

andmdash; Shared by two cores in i.MX 6DualLite

andbull; Two Master AXI bus interfaces output of L2 cache

andbull; Frequency of the core (including NEON and L1 cache), as per Table 8.

andbull; NEON MPE coprocessor

andmdash; SIMD Media Processing Architecture

andmdash; NEON register file with 32x64-bit general-purpose registers

andmdash; NEON Integer execute pipeline (ALU, Shift, MAC)

andmdash; NEON dual, single-precision floating point execute pipeline (FADD, FMUL)

andmdash; NEON load/store and permute pipeline

The SoC-level memory system consists of the following additional components:

andmdash; Boot ROM, including HAB (96 KB)

andmdash; Internal multimedia / shared, fast access RAM (OCRAM, 128 KB)

andmdash; Secure/non-secure RAM (16 KB)

andbull; External memory interfaces: The i.MX 6Solo/6DualLite processors support latest, high volume, cost effective handheld DRAM, NOR, and NAND Flash memory standards.

andmdash; 16/32-bit LP-DDR2-800, 16/32-bit DDR3-800 and DDR3L-800 in i.MX 6Solo; 16/32/64-bit LP-DDR2-800, 16/32/64-bit DDR3-800 and DDR3L-800, supporting DDR interleaving mode for 2x32 LPDDR2-800 in i.MX 6DualLite

andmdash; 8-bit NAND-Flash, including support for Raw MLC/SLC, 2 KB, 4 KB, and 8 KB page size, BA-NAND, PBA-NAND, LBA-NAND, OneNANDandtrade; and others. BCH ECC up to 40 bit.

andmdash; 16/32-bit NOR Flash. All WEIMv2 pins are muxed on other interfaces.

andmdash; 16/32-bit PSRAM, Cellular RAM

andnbsp;

Introduction

The i.MX 6Solo/6DualLite automotive and infotainment processors represent the latest achievement in integrated multimedia-focused products offering high-performance processing with a high degree of functional integration. These processors are designed considering the needs of the growing automotive infotainment, telematics, HMI, and display-based cluster markets.

The processors feature advanced implementation of single/dual Armandreg;Cortexandreg;-A9 core, which operates at speeds of up to 1GHz. They include 2D and 3D graphics processors, 1080p video processing, and integrated power management. Each processor provides a 32/64-bit DDR3/DDR3L/LPDDR2-800 memory interface and a number of other interfaces for connecting peripherals, such as WLAN, Bluetoothandreg;, GPS, hard drive, displays, and camera sensors.
