MC14013BDR2G Dual D Flip-Flop 3V-18V Operation Set/Reset High Noise Immunity Low Power SOIC-14 Industrial Grade

MC14013BDR2G Dual D Flip-Flop 3V-18V Operation Set/Reset High Noise Immunity Low Power SOIC-14 Industrial Grade

The MC14013B dual type D flip-flop is constructed with MOS P-channel and N-channel enhancement mode devices in a single monolithic structure. Each flip-flop has independent Data, (D), Direct Set, (S), Direct Reset, (R), and Clock (C) inputs and complementary outputs (Q and Q ). These devices may be used as shift register elements or as type T flip-flops for counter and toggle applications.

Features

 Static Operation

 Diode Protection on All Inputs

 Supply Voltage Range = 3.0 Vdc to 18 Vdc

 Logic Edge-Clocked Flip-Flop Design

 Logic State is Retained Indefinitely with Clock Level either High or Low; Information is Transferred to the Output only on the Positive-going Edge of the Clock Pulse

 Capable of Driving Two Low-power TTL Loads or One Low-power Schottky TTL Load Over the Rated Temperature Range

 Pin-for-Pin Replacement for CD4013B

 NLV Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC-Q100 Qualified and PPAP Capable

 These Devices are Pb-Free, Halogen Free and are RoHS Compliant

Applications

1. Digital Logic Circuits
  Sequential Control: Used in clock-synchronized systems and state machine designs for signaldelay or pulse shaping.
  Data Latching: Temporarily stores data in microcontroller interfaces to prevent bus contention(e.g., button debouncing, sensor signal retention).
2. Industrial Control Systems
  Motor/Relay Control: Maintains start/stop states in PLC-based sequential control systems.

  Safety Logic: Works with sensors to build interlock circuits (e.g., emergency stop signalretention and reset).

3.Communication & Signal Processing
  Frequency Division: Divides high-frequency clock signals (e.g., converting 1MHz to 500kHz).
  Serial-to-Parallel Conversion: Assists in converting low-speed serial data to parallel data.
4.Consumer Electronics
  User Interface Control: Remembers button states (e.g., toggle switches for power on/off).
  Display Driving: Controls scanning sequences for LEDs or LCDs.

5.Automotive Electronics
  State Memory Unit: Stores transient signals (e.g., door switches, fault codes) until manuallyreset.
6. Test & Measurement Equipment
  Signal Synchronization: Triggers specific waveform captures in oscilloscopes or logicanalyzers.
