IRFB260NPBF 200V 46A MOSFET 36mΩ RDS(on) Fast Switching TO-220 Avalanche Rated Ideal for Power Converters & Motor Drives
FEATURES
1. Core Electrical Characteristics
Voltage/Current Ratings
200V Drain-Source Breakdown Voltage (V<sub>DsS</sub>)- Supports medium/high-e)voltage applications like motor drives and power conversion.
46A Continuous Drain Current (l<sub>D</sub> @25°C)- High current-carrying capability0for high-power scenarios.
180A Pulsed Drain Current (l<sub>DM</sub>)- Withstands instantaneous high-current0surges.
Conduction characteristics
Ultra-Low On-Resistance-Only 36m2 (V<sub>GS</sub>=10V), minimizing conductionlosses.
Low Gate charge (Q<sub>g</sub>=110nC)-lmproves switching efficiency and reducesdrive power consumption.
Switching Performance
Fast Switching speed -
Turn-on delay time(t<sub>d(on)</sub>)= 13ns
Turn-off delay time (t<sub>d(off)</sub>)= 60ns
Low Reverse Recovery Charge (Q<sub>rr</sub>=1.3uC)-0ptimizes body diodeDperformance.
2. Reliability Design
100% Avalanche Tested - Ensures reliability under extreme voltage transients.
Wide Operating Temperature Range--55°C to +175°C, suitable for harsh environments.
Enhanced Body Diode - Fast reverse recovery, reducing switching losses.
3. Package & Thermal Management
TO-220 Package
Standard three-pin design for easy installation and heat dissipation.
Low thermal resistance (R<sub>0jC</sub>=0.5°C/), supporting high-power-densityapplications.
4. Protection & compatibility
Gate-Source Voltage Range (V<sub>Gs</sub>)- +20V, preventing gate overvoltage damage.
Logic-Level Compatible (V<sub>GS(th)</sub>=2-4V)- Can be directly driven by MCUs ordriver lCs.
