ADC0834CCN 8-Bit ADC 4-Channel Input 5V Supply Serial I/O Low Power 0°C to +70°C Easy MCU Interface Cost-Effective Solution

ADC0834CCN 8-Bit ADC 4-Channel Input 5V Supply Serial I/O Low Power 0anddeg;C to +70anddeg;C Easy MCU Interface Cost-Effective Solution

andnbsp;

FEATURES andnbsp;

andbull; TIMICROWIRE Compatibleandmdash;Direct Interface to COPS Family Processors

andbull; EasyInterface to All Microprocessors, or Operates andldquo;Stand-Aloneandrdquo;

andbull; Operates Ratiometrically or with 5 VDC Voltage Reference

andbull; NoZeroor Full-Scale Adjust Required

andbull; 2-, 4- or 8-Channel Multiplexer Options with Address Logic

andbull; Shunt Regulator Allows Operation with High Voltage Supplies

andbull; 0Vto5VInput Range with Single 5V Power Supply

andbull; Remote Operation with Serial Digital Data Link

andbull; TTL/MOS Input/Output Compatible

andbull; 0.3 in. Standard Width, 8-, 14- or 20-Pin PDIP Package

andbull; 20Pin PLCC Package (ADC0838-N Only)

andbull; SOICPackage

andnbsp;

KEY SPECIFICATIONS

andbull; Resolution: 8 Bits

andbull; Total Unadjusted Error: andplusmn;andfrac12; LSB and andplusmn;1 LSB

andbull; Single Supply: 5 VDC

andbull; LowPower: 15 mW

andbull; Conversion Time: 32 andmu;s

andnbsp;

DESCRIPTION

The ADC0831 series are 8-bit successive approximation A/D converters with a serial I/O and configurable input multiplexers with up to 8 channels. The serial I/O is configured to comply with the TI MICROWIRE serial data exchange standard for easy interface to the COPS family of processors, and can interface with standard shift registers or andmu;Ps.

The 2-, 4- or 8-channel multiplexers are software configured for single-ended or differential inputs as well as channel assignment.

The differential analog voltage input allows increasing the common-mode rejection and offsetting the analog zero input voltage value. In addition, the voltage reference input can be adjusted to allow encoding any smaller analog voltage span to the full 8 bits of resolution.
