IPA60R360P7SXKSA1 600V CoolMOS™ 360mΩ RDS(on) 11A Current Ultra-Low Switching Losses High Efficiency Robust ESD Protection TO-220 Package for SMPS & Industrial Apps

Features

•Suitableforhardandsoftswitching(PFCandLLC)duetoanoutstanding commutationruggedness

•Significantreductionofswitchingandconductionlosses

•ExcellentESDrobustness>2kV(HBM)forallproducts

•BetterRDS(on)/packageproductscomparedtocompetitionenabledbya lowRDS(on)*A(below1Ohm*mm²)

Benefits

•Easeofuseandfastdesign-inthroughlowringingtendencyandusage acrossPFCandPWMstages

•Simplifiedthermalmanagementduetolowswitchingandconduction losses

•Increasedpowerdensitysolutionsenabledbyusingproductswith smallerfootprintandhighermanufacturingqualitydueto>2kVESD protection •Suitableforawidevarietyofapplicationsandpowerranges

Potentialapplications

PFCstages,hardswitchingPWMstagesandresonantswitchingstages fore.g. PCSilverbox,Adapter,LCD&PDPTV,Lighting,Server,Telecom andUPS.

Productvalidation

QualifiedaccordingtoJEDECStandard

MOSFET

600V CoolMOSª P7 Power Device

TheCoolMOS™7thgenerationplatformisarevolutionarytechnologyfor highvoltagepowerMOSFETs,designedaccordingtothesuperjunction (SJ)principleandpioneeredbyInfineonTechnologies.The600V CoolMOS™P7seriesisthesuccessortotheCoolMOS™P6series.It combinesthebenefitsofafastswitchingSJMOSFETwithexcellentease ofuse,e.g.verylowringingtendency,outstandingrobustnessofbody diodeagainsthardcommutationandexcellentESDcapability. Furthermore,extremelylowswitchingandconductionlossesmake switchingapplicationsevenmoreefficient,morecompactandmuch cooler.

INFORMATION

Category	Discrete Semiconductor Products Transistors FETs, MOSFETs Single FETs, MOSFETs
Mfr	Infineon Technologies
Series	CoolMOS™ P7
Packaging	Tube
Part Status	Active
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	600 V
Current - Continuous Drain (Id) @ 25°C	9A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Max) @ Id, Vgs	360mOhm @ 2.7A, 10V
Vgs(th) (Max) @ Id	4V @ 140µA
Gate Charge (Qg) (Max) @ Vgs	13 nC @ 10 V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	555 pF @ 400 V
FET Feature	-
Power Dissipation (Max)	22W (Tc)
Operating Temperature	-40°C ~ 150°C (TJ)
Grade	-
Qualification	-
Mounting Type	Through Hole
Supplier Device Package	PG-TO220-FP
Package / Case	TO-220-3 Full Pack
Base Product Number	IPA60R360
