NLAS2750MUTAG Low On-Resistance (0.6andOmega;) High-Speed Switching 1.8V-5.5V Wide Voltage ESD Protection Tiny SOT-23 Package RoHS Compliant Ideal for Portable andamp; IoT Devices
andnbsp;
Features
andbull; Capable to Switch Negative Swing Audio Signals Without Requiring a DC Blocking Capacitor
andbull; Low Onandminus;resistance (RON)
andbull; Low Voltage Digital Control Logic: (VINH = 1.4 V @ VCC = 2.7 V to 4.3 V)
andbull; Low Power Consumption (ICC andle; 250 nA)
andbull; Space Saving 1.4 mm x 1.8 mm Package UQFN Package
andbull; This is a Pbandminus;Free Device
andnbsp;
Typical Applications
andbull; Cellular Phones
andbull; Portable Media Players
andnbsp;
Description
The NLAS2750MUTAG is a high-efficiency, low-voltage single-pole double-throw (SPDT)analog switch designed for portable devices, loT applications, and signal routing systems.With an ultra-low on-resistance (0.62 typical) and minimal power consumption, this switchensures high signal integrity while reducing voltage drop and distortion.
Key Features andamp; Benefits
1. Ultra-Low On-Resistance (0.62)- Minimizes signal loss and power dissipation, making itideal for precision analog and digital switching.
2. Wide Voltage Range (1.8V to 5.5v)- Supports multiple logic levels, ensuring compatibilitywith battery-powered devices (Li-ion, 3.3V/5V systems).
3. High-speed switching (Fast Turn-On/Off)- Enables quick signal routing for dataacquisition, audio switching, and multiplexing applications.
4. Robust ESD Protection (andplusmn;8kV HBM) - Enhances reliability in harsh environments, protectingsensitive circuits from electrostatic discharge.
Compact SOT-23 Package - Saves board space in wearables, smartphones, and loT sensors5.
while allowing easy PCB integration.
6. Low Power Consumption (Near-Zero Leakage Current)- Extends battery life in portableelectronics.
7. RoHS Compliant andamp; Lead-Free- Meets global environmental standards for safemanufacturing and disposal.
