IR2104STRPBF High-Voltage Half-Bridge Driver with 600V Rating 200mA Output Fast Switching Low Quiescent Current Robust SOIC-8 Package & UVLO Protection

IR2104STRPBF High-Voltage Half-Bridge Driver with 600V Rating 200mA Output Fast Switching Low Quiescent Current Robust SOIC-8 Package & UVLO Protection

 Features

• Floating channel designed for bootstrap operation

   Fully operational to +600V

   Tolerant to negative transient voltage

   dV/dt immune

• Gate drive supply range from 10 to 20V

• Undervoltage lockout

• 3.3V, 5V and 15V input logic compatible

• Cross-conduction prevention logic

• Internally set deadtime

• High side output in phase with input

• Shut down input turns off both channels

• Matched propagation delay for both channels

• Also available LEAD-FREE

Description

The IR2104(S) are high voltage, high speed power MOSFET and IGBT drivers with dependent high and low side referenced output channels. Proprietary HVIC and latch immune CMOS technologies enable ruggedized monolithic construction. The logic input is compatible with standard CMOS or LSTTL output, down to 3.3V logic. The output drivers feature a high pulse current buffer stage designed for minimum driver cross-conduction. The floating channel can be used to drive an N-channel power MOSFET or IGBT in the high side configuration which

Applications

Motor Drive
Brushless DC (BLDC) motor drive
Stepper motor drive
Servo motor control

Power & Inverters
DC-AC inverters (e.g., solar inverters, UPS)

Switch-mode power supplies (SMPS)
High-frequency power conversion
Industrial Automation
Industrial motor control

Robotic drive systems

Solenoid valve driving

Automotive Electronics
Electric vehicle (EV) motor control
On-board chargers (OBC)

Electric power steering (EPS)
Consumer Electronics & Appliances
Inverter air conditioner/refrigerator compressor drive

Power tools (e.g., drills, cutters)

Drone ESCs (Electronic Speed Controllers)
