SN74LVC1G32DBVR Single 2-Input OR Gate 1.65-5.5V Supply 10ns Propagation Delay SOT-23-5 -40°C to +125°C

SN74LVC1G32DBVR Single 2-Input OR Gate 1.65-5.5V Supply 10ns Propagation Delay SOT-23-5 -40anddeg;C to +125anddeg;C

andnbsp;

Features andnbsp;

andbull; Available in the Ultra-Small 0.64 mm2 Package (DPW) with 0.5-mm Pitch

andbull; Supports 5-V VCC Operation

andbull; Inputs Accept Voltages to 5.5-V

andbull; Supports Down Translation to VCC

andbull; Maxtpd of 3.6 ns at 3.3-V

andbull; LowPower Consumption, 10-andmicro;A Max ICC

andbull; andplusmn;24-mA Output Drive at 3.3-V

andbull; Ioff Supports Live Insertion, Partial-Power-Down Mode, and Back-Drive Protection

andbull; Latch-Up Performance Exceeds 100 mA Per JESD 78, Class II

andbull; ESDProtection Exceeds JESD 22andndash; 2000-V Human-Body Model (A114-A)andndash; 200-V Machine Model (A115-A)andndash; 1000-V Charged-Device Model (C101)

andnbsp;

Applications

andbull; AVReceiver

andbull; Blu-ray Player and Home Theater

andbull; Digital Picture Frame (DPF)

andbull; Embedded PC

andbull; IPPhone: Wireless

andbull; High-Speed Data Acquisition and Generation

andbull; Motor Control: High-Voltage

andbull; Optical Networking: Video Over Fiber and EPON

andbull; Personal Navigation Device (GPS)

andbull; Portable Media Player

andbull; Private Branch Exchange (PBX)

andbull; Server PSU

andbull; SSD: Internal and External

andbull; TV:LCD/Digital and High-Definition (HDTV)

andbull; Telecom Shelter: Power Distribution Unit (PDU), Power Monitoring Unit (PMU), Wireless Battery Monitoring, Remote Electrical Tilt Unit (RET), Remote Radio Unit (RRU), Tower Mounted Amplifier (TMA)

andbull; Video Conferencing: IP-Based HD

andbull; Vector Signal Analyzer and Generator

andbull; WiMAXandWireless Infrastructure Equipment

andbull; Wireless Headset, Keyboard, Mouse, and Repeater

andnbsp;

Description

This single 2-input positive-OR gate is designed for 1.65-V to 5.5-V VCC operation. The SN74LVC1G32 device performs the Boolean function inpositivelogic. Y = A + B or Y = andbull; A B The CMOS device has high output drive while maintaining low static power dissipation over a broad VCC operating range. The SN74LVC1G32 device is available in a variety of packages, including the ultra-small DPW package with a body size of 0.8 andtimes; 0.8 mm.
