URB4805YMD-10WR3 5V 10W DC-DC Converter 4:1 Wide Input (9-36V) 94% Efficiency SIP-7 -40°C to +85°C

Large Image : URB4805YMD-10WR3 5V 10W DC-DC Converter 4:1 Wide Input (9-36V) 94% Efficiency SIP-7 -40°C to +85°C

Product Details:

Place of Origin:	China
Brand Name:	Mornsun
Certification:	CE,ROHS
Model Number:	URB4805YMD-10WR3

Payment & Shipping Terms:

Minimum Order Quantity:	1pcs

Contact Now

Detailed Product Description

Frequency Stability:	±50ppm	Frequency Tolerance:	±30ppm
Operating Temperature:	-40°C ~ 85°C	Load Capacitance:	18pF
Package / Case:	HC-49/US	Name:	Passive Electronic Components
Highlight:	Wide Input DC-DC Converter , 4:1 DC-DC Converter , 10W DC-DC Converter

URB4805YMD-10WR3

andnbsp;

FEATURES

 Ultra-wide4:1inputvoltagerange

 Highefficiencyupto88%

 No-loadpowerconsumptionaslowas0.12W

 I/Oisolationtestvoltage1.5kVDC

 Inputunder-voltageprotection,output short-circuit,over-current,over-voltageprotection

 Operatingambienttemperaturerange:-40℃to +85℃

 MeetsCISPR32/EN55032CLASSA,withoutextra components

 Inputreversepolarityprotectionavailablewith Chassis(A2S)or35mmDIN-Railmounting(A4S) version

 MeetsEN50155railwaystandard

 Industrystandardpin-out

andnbsp;

DESCRIPTION

URA_YMD-10WR3andamp;URB_YMD-10WR3seriesareisolated10WDC-DCconverterproductsfeatureanultra-widewith4:1inputvoltagewith efficienciesofupto88%,1500VDCinputtooutput isolation,operatingambienttemperaturerangeof-40℃to+85℃, inputunder-voltage protection,outputshort-circuit,over-current,over-voltageprotection.TheymeetCLASSAofCISPR32/EN55032EMIstandardswithout externalcomponents,optionalpackagesareofferedforchassisorDIN-railmounting(A2S,A4S),addingadditional inputreversepolarity protectionandtheyarewidelyusedinapplicationssuchasindustrialcontrol,electricpower, instruments,communicationandrailway applications.

andnbsp;

INFORMATION

Category	Power Supplies - Board Mount DC DC Converters	andnbsp;
Manufacturer	Mornsun America, LLC	andnbsp;
Series	URB4805YMD-10WR3 (10W)	andnbsp;
Packaging	Tube	andnbsp;
Part Status	Not For New Designs	andnbsp;
Type	Isolated Module	andnbsp;
Number of Outputs	1	andnbsp;
Voltage - Input (Min)	18V	andnbsp;
Voltage - Input (Max)	75V	andnbsp;
Voltage - Output 1	5V	andnbsp;
Voltage - Output 2	-	andnbsp;
Voltage - Output 3	-	andnbsp;
Voltage - Output 4	-	andnbsp;
Current - Output (Max)	2A	andnbsp;
Power (Watts)	10 W	andnbsp;
Voltage - Isolation	1.5 kV	andnbsp;
Applications	ITE (Commercial)	andnbsp;
Features	-	andnbsp;
Operating Temperature	-40anddeg;C ~ 85anddeg;C (With Derating)	andnbsp;
Efficiency	83%	andnbsp;
Mounting Type	Through Hole	andnbsp;
Package / Case	6-DIP Module, 5 Leads	andnbsp;
Size / Dimension	1.00andquot; L x 1.00andquot; W x 0.46andquot; H (25.4mm x 25.4mm x 11.7mm)	andnbsp;
Supplier Device Package	-	andnbsp;
Control Features	-	andnbsp;
Approval Agency	CB, CE, cURus	andnbsp;
Base Product Number	-

andnbsp;

Drawing
