Features

andnbsp; Industry-standard PLCC-2 package

andnbsp; High-reliability LED package

andnbsp; High brightness using AlInGaP and InGaN dice technologies

andnbsp; Available in full selection of colors

andnbsp; Super wide viewing angle at 120anddeg;

andnbsp; Available in 8-mm carrier tape on 7-in. reel (2000 pieces)

andnbsp; Compatible with IR soldering process

andnbsp;

Description

This family of Broadcomandreg; SMT LEDs is packaged in the industry-standard PLCC-2 package. These SMT LEDs have high-reliability performance and are designed to work under a wide range of environmental conditions. This high-reliability feature makes them ideally suited to be used under harsh interior automotive conditions, as well as interior sign application conditions.

To facilitate easy pick-and-place assembly, the LEDs are packed in EIA-compliant tape and reel. Every reel will be shipped in single intensity and color bin, except the red color, to provide close uniformity.

These LEDs are compatible with IR solder reflow process.

The super wide viewing angle at 120anddeg; makes these LEDs ideally suited for panel, push button, or general backlighting in automotive interior, office equipment, industrial equipment, and home appliances. The flat top emitting surface makes it easy for these LEDs to mate with light pipes. With the built-in reflector pushing up the intensity of the light output, these LEDs are also suitable to be used as LED pixels in interior electronic signs.

andnbsp;

Applications

andnbsp;Interior automotive

andnbsp; andndash; Instrument panel backlighting

andnbsp; andndash; Central console backlighting

andnbsp; andndash; Switch/push button backlighting

andnbsp;Electronic signs and signals

andnbsp; andndash; Interior full color sign

andnbsp; andndash; Variable message sign

andnbsp;Office automation, home appliances, industrial equipment

andnbsp; andndash; Front panel backlighting

andnbsp; andndash; Push button backlighting

andnbsp; andndash; Display backlighting
