LM3410YSD
andnbsp;
Features
andbull; Qualified for Automotive Applications
andbull; AEC-Q100 Test Guidance With the Following:andndash; Device Temperature Grade 1:andndash;40anddeg;C to 125anddeg;C Ambient Operating Temperature Rangeandndash; Device HBM ESD Classification Level 2andndash; Device CDM ESD Classification Level C6
andbull; Space-Saving SOT-23 and WSON Packages
andbull; Input Voltage From 2.7 V to 5.5 V
andbull; Output Voltage From 3 V to 24 V
andbull; 2.8-A (Typical) Switch Current Limit
andbull; High Switching Frequencyandndash; 525KHz(LM3410Y)andndash; 1.6 MHz (LM3410X)
andbull; 170-mandOmega; NMOSSwitch
andbull; 190-mV Internal Voltage Reference
andbull; Internal Soft Start
andbull; Current-Mode, PWM Operation
andbull; Thermal Shutdown
andnbsp;
Applications
andbull; LEDBacklight Current Sources
andbull; LiIon Backlight OLED and HB LED Drivers
andbull; Handheld Devices
andbull; LEDFlash Drivers
andbull; Automotive Applications
andnbsp;
Description
The LM3410 and LM3410-Q1 constant current LED driver are a monolithic, high frequency, PWM DC-DC converter, available in 6-pin WSON, 8-pin MSOP PowerPadandtrade;, and 5-pin SOT-23 packages. With a minimum of external components the LM3410 and LM3410-Q1 are easy to use. It can drive 2.8-A (typical) peak currents with an internal 170-mandOmega; NMOS switch. Switching frequency is internally set to either 525 kHz or 1.6 MHz, allowing the use of extremely small surface mount inductors and chip capacitors. Even though the operating frequency is high, efficiencies up to 88% are easy to achieve. External shutdown is included, featuring an ultra-low standby current of 80 nA. The LM3410 and LM3410 Q1 use current-mode control and internal compensation to provide high-performance over a wide range of operating conditions. Additional features include PWM dimming, cycle-by-cycle current limit, and thermal shutdown.
