BQ24780SRUYR 10A Battery Charger 5-24V Input I2C Control 1% Voltage Accuracy Package / Case 28-WFQFN Exposed Pad -40°C to +85°C

BQ24780SRUYR

andnbsp;

Features andnbsp;

andbull; Industrial Innovative Charge Controller With Hybrid Power Boost Modeandndash; Adapter and Battery Provides Power to System Together for Intelandreg; CPU Turbo Modeandndash; Ultra-Fast Transient Response of 150 andmicro;s to Enter Boost Modeandndash; Hybrid Power Boost Mode from 4.5- to 24-V Systemandndash; Charge 1- to 4-Cell Battery Pack from 4.5- to 24-V Adapter

andbull; High Accuracy Power and Current Monitoring for CPU Throttlingandndash; Comprehensive PROCHOT Profileandndash; andplusmn;2%Current Monitor Accuracyandndash; andplusmn;5%System Power Monitor Accuracy (PMON)

andbull; Automatic NMOS Power Source Selection from Adapter or Batteryandndash; ACFETFast Turn on in 100 andmicro;s

andbull; Programmable Input Current, Charge Voltage, Charge and Discharge Current Limitandndash; andplusmn;0.4% Charge Voltage (16-mV step)andndash; andplusmn;2%Input Current (128-mA/step)andndash; andplusmn;2%Charge Current (64-mA/step)andndash; andplusmn;2%Discharge Current (512-mA/step)

andbull; High Integrationandndash; Battery LEARN Functionandndash; Battery Present Monitorandndash; Boost Mode Indicatorandndash; Loop Compensationandndash; BTSTDiode

andbull; Enhanced Safety Features for Overvoltage Protection, Overcurrent Protection, Battery, Inductor, and MOSFET Short-Circuit Protection

andbull; Switching Frequency: 600 kHz, 800 kHz, and 1 MHz

andbull; Realtime System Control on ILIM Pin to Limit Charge and Discharge Current

andbull; 0.65 mA Adapter Standby Quiescent Current for Energy Star

andnbsp;

Applications

andbull; Notebook, Ultrabook, Detachable, and Tablet PC

andbull; Handheld Terminal

andbull; Industrial and Medical Equipment

andbull; Portable Equipment

andnbsp;

Description

The bq24780S device is a high-efficiency, synchronous battery charger, offering low component count for space-constrained, multi-chemistry battery charging applications.

The bq24780S device supports hybrid power boost mode (previously called andquot;turbo boost modeandquot;). It allows battery discharge energy to system when system power demand is temporarily higher than adapter maximum power level. Therefore, adapter does not crash.

The bq24780S device uses two charge pumps to separately drive N-channel MOSFETs (ACFET, RBFET, and BATFET) for automatic system power source selection.

Through SMBus, system power management microcontroller programs input current, charge current, discharge current, and charge voltage DACs with high regulation accuracies.

The bq24780S device monitors adapter current (IADP), battery discharge current (IDCHG), and system power (PMON) for host to throttle back CPU speed or reduce system power when needed.

The bq24780S device charges 1-, 2-, 3-, or 4-series Li+ cells.
