TPS62290TDRVRQ1 6 WDFN Power Management (PMIC) Exposed Pad Electronic Circuit Components In stock

TPS62290TDRVRQ1

1 Features 1 • Qualified for Automotive Applications • High Efficiency Step-Down Converter • Output Current up to 1000 mA • VIN Range From 2.3 V to 6 V • 2.25-MHz Fixed Frequency Operation • Power Save Mode at Light Load Currents • Output Voltage Accuracy in PWM mode ±1.5% • Fixed Output Voltage Options • Typical 15-µA Quiescent Current • 100%Duty Cycle for Lowest Dropout • Voltage Positioning at Light Loads • Available in a 2-mm × 2-mm × 0.8-mm SON Package

2 Applications • Automotive Infotainment and Clusters– Instrument Clusters– HeadUnits and Displays– Radios and Navigation • Advanced Driver Assistance System (ADAS)– Front Cameras– Blind Spot Monitoring– Lane Departure Warning– Park Assist • HEV/EV Onboard Charger

3 Description The TPS6229x-Q1 is a highly efficient synchronous step-down buck converter optimized for automotive low input voltage applications, and provides up to 1000-mA output current.. With an input voltage range of 2.3 V to 6 V, and an output voltage accuracy of 1.5%, the device powers a large variety of automotive applications. The TPS6229x-Q1 operates at 2.25-MHz fixed switching frequency and enters Power Save Mode operation with typical quiescent current of 15 µA at light load currents to maintain a high efficiency over the entire load current range. The Power Save Mode is optimized for low output voltage ripple. For low noise applications, the device can be forced into fixed frequency PWM mode by pulling the MODE pin high. In the shutdown mode, the current consumption is reduced to less than 1 µA. The TPS6229x-Q1 allows the use of small inductors and capacitors to achieve a small solution size. The TPS6229x-Q1 is available in a 2-mm × 2-mm 6-pin SON package.

Our advantage :

• High quality products --- our offers are 100% new and original, ROHS
• Competitive price --- good Purchase channels with good price.
• Professional service --- strict quality testing before the shipment, and perfect after-sales service after the purchase.
• Adequate inventory --- With the support of our strong Purchasing team,
• Fast delivery --- we will ship the goods within 1-3 working days after the payment confirmed.

be sure to meet your need for all kinds of components. ^_^


Product List
Supply a Series of Electronic Components, full range of semiconductors, active & passive Components.We can help you to get all for bom of the PCB,IN a word, you can get one-stop solution here,


The offers including:
Integrated Circuit, Memory ICs, Diode, Transistor , Capacitor, Resistor, Varistor, Fuse, Trimmer & Potentiometer, Transformer, Battery, Cable, Relay, Switch, Connector, Terminal Block, Crystal & Oscillator, Inductor, Sensor, Transformer, IGBT Driver, LED,LCD, Convertor, PCB (Printed Circuit Board),PCBA (PCB Assembly)

Strong in Brand:
Microchip, MAX, AD, TI, ATMEL, ST, ON, NS, Intersil, Winbond, Vishay, ISSI, Infineon, NEC, FAIRCHILD, OMRON,YAGEO, TDK, etc
