| Frequency Stability: | ±50ppm | Frequency Tolerance: | ±30ppm |
|---|---|---|---|
| Operating Temperature: | -40°C ~ 85°C | Load Capacitance: | 18pF |
| Package / Case: | HC-49/US | Name: | Passive Electronic Components |
| High Light: | 18PF SMD Passive Electronic Components,25.0000MHZ Passive Electronic Components,Surface Mount SMD Crystal |
||
ECS-250-18-5PX-F-TR
100% Replacement substitute
The CSM-7X is an excellent choice for the SMD versions of the
HC-49USX leaded crystal. The CSM-7X has a case height of
4.3 mm Max in a resistance weld metal package. A package
profile of 3.2 mm Max is also available.
SOLDER PROFILE
Peak solder Temp +260°C Max 10 sec Max.
2 Cycles Max.
MSL 1, Lead Finish Sn/Cu Matte
EQUIVALENT SERIES RESISTANCE/MODE OF OSCILLATION
| Frequency (MHz) | ESR Ω Max. | Mode of Osc. |
| 3.57~4.999 | 150 | Fundamental |
| 5.00~5.999 | 80 | Fundamental |
| 6.00~6.999 | 70 | Fundamental |
| 7.00~8.999 | 60 | Fundamental |
| 9.00~12.999 | 50 | Fundamental |
| 13.00~19.999 | 40 | Fundamental |
| 20.000~40.000 | 30 | Fundamental |
| 40.000~70.000 | 80 | 3rd Overtone |
