Product Details:
Payment & Shipping Terms:
|
| Product Name: | Rf Coaxial Cable | Connector: | SMA-MMCX Right Angle |
|---|---|---|---|
| Cable: | RG174 | Length Of The Cable: | 10cm, 20cm, 40cm Or Customized |
| Connector Color: | Gold | Impedance: | 50 Ohm |
| High Light: | connector coaxial cable,hd coaxial cable |
||
50 ohms coax cable pigtail cable ,SMA Male plug to MMCX Right angle with RG174 Cable
TOP-SMA-MMCX RG174 cable
Product introduction:
it is a SMA male to MMCX right angle cable using RG174 coax.
Cable length can be custom made.
· External Material : Plastic, Alloy; Cable Length : 5cm,10cm,15cm or customized.
· Connector Color : gold
· Cable Fitting: RG174
· Net Weight : depends on the cable length,
· Package Content : 1 x SMA Male to SMA Female Nut Bulkhead Extension RF Coax pigtail jumper Cable RG174
Specification:
| Key Specifications | |
| Connector Series 1 | SMA |
| Connector Gender 1 | Male |
| Connector Polarity 1 | Standard |
| Connector Angle 1 | Straight or Right angle |
| Connector Mount Method 1 | None |
| Connector Impedance 1 | 50 |
| Connector Series 2 | MMCX |
| Connector Gender 2 | Male |
| Connector Polarity 2 | Standard |
| Connector Angle 2 | Right angle |
| Connector Mount Method 2 | Bulkhead |
| Connector Impedance 2 | 50 |
| RF Cable Part Number | RG174A/U |
| RF Cable Type | RG174 |
| RF Cable Impedance | 50 |
Cable information:
| RG174 | ||
| PTFE Insulated PTFE | ||
| Construction | ||
| Item | Material | Diameter(Inch/mm) |
| Inner conductor | silver plated copper clad steel | 7/0.0067+-0.001 7/0.17+_0.02 |
| Dielectric | PTFE | 0.06+_0.003 1.52+_0.08 |
| Shield | 95% silver plated copper braid | 0.078+_0.003 1.98+_0.08 |
| Jacket | FEP | 0.098+_0.004 2.49+_0.1 |
RF Cable /RF coaxial cable/ pigtail cable
RF pigtail cable is used for all RF/wireless equipments.
RF pigtail cable
GSM System
GPS Navigation system
Wireless communication system
Car radio
LAN System
COMPATIBLE CONNECTORS:
SMA,SMB,SMC,MCX,MMCX,N,FME,TNC,
BNC,FAKRA,GT5,U.FL, GSC,IPEX etc
COMPATIBLE CABLES:
IMPEDANCE 50Ω/75Ω/93Ω
RG405/U, RG402/U, RG316/U, RG223/U
RG188/U, RG179/U, RG174/U, RG142/U
RG141/U, RG59/U, RG58/U, RG8/U, RG6/U
